Specifications
1.Low temperature circulating pump2.Multipurpose;
3.Hight quality;
4.Well After Sale;
5.Easy to operation
Low temperature circulating pump
1.Technical Data:
Model | Volume | No load minimum temperature | Cooling capacity | Flow | Lift | Coolant temperature | Temperature precision | Power supply(V) |
DLSB-5/10 | 5L | -15°C | 1328-319°C | 20L/min | 4-6m | -10°C | ±0.2°C | 220 |
DLSB-5/20 | -24 | 1328-319 | -20°C | ±0.2 | 220 | |||
DLSB-5/25 | -27 | 1894-447 | -25°C | ±0.2 | 220 | |||
DLSB-5/30 | -33 | 2733-627 | -30°C | ±0.2 | 220 | |||
DLSB-5/40 | -42 | 2036-602 | -40°C | ±0.2 | 220 | |||
DLSB-5/60 | -62 | 2036-330 | -60°C | ±0.2 | 220/380 | |||
DLSB-5/80 | -82 | 2036-180 | -80°C | ±0.2 | 220/380 | |||
DLSB-5/120 | -123 | 3888-160 | -120°C | ±0.2 | 220/380 | |||
DLSB-10/10 | -14 | 1894-884 | -10°C | ±0.2 | 220 | |||
DLSB-10/20 | -23 | 2733-813 | -20°C | ±0.2 | 220 | |||
DLSB-10/25 | 10L | -28 | 3256-990 | -25°C | ±0.2 | 220 | ||
DLSB-10/30 | -32 | 2036-1022 | -30°C | ±0.2 | 220 | |||
DLSB-10/40 | -42 | 2628-748 | -40°C | ±0.2 | 220 | |||
DLSB-10/60 | -62 | 3679-510 | -60°C | ±0.2 | 220/380 | |||
DLSB-10/80 | -82 | 3679-160 | -80°C | ±0.2 | 220/380 | |||
DLSB-10/120 | -122 | 4997-120 | -120°C | ±0.2 | 380 | |||
DLSB-20/20 | 20L | -24 | 3255-990 | -20°C | ±0.2 | 220 | ||
DLSB-20/30 | -33 | 2628-1350 | -30°C | ±0.2 | 220 | |||
DLSB-20/40 | -42 | 3809-989 | -40°C | ±0.2 | 380 | |||
DLSB-20/60 | -62 | 4997-510 | -60°C | ±0.2 | 220 | |||
DLSB-20/80 | -82 | 7828-230 | -80°C | ±0.2 | 380 | |||
DLSB-20/120 | -122 | 7828-160 | -120°C | ±0.2 | 380 | |||
DLSB-30/20 | 30L | -24 | 6249-1825 | -20°C | ±0.2 | 220 | ||
DLSB-30/30 | -32 | 3809-1801 | -30°C | ±0.2 | 380 | |||
DLSB-30/40 | -42 | 4829-1140 | -40°C | ±0.2 | 380 | |||
DLSB-30/60 | -62 | 4997-160 | -60°C | ±0.2 | 380 | |||
DLSB-30/80 | -82 | 7828-180 | -80°C | ±0.2 | 380 | |||
DLSB-30/120 | -122 | 10364-210 | -120°C | ±0.2 | 380 |
(1)Air-cooled and hermetically sealed compressor units(import) withdependable quality;
(2)The dedicated and high-quality relays, protective devices and capacitors of the refrigerating units;
(3)Digital Read Out of temperature and microprocessor controller for temperature, simple and easier to see;
(4)It can be matched with a variety of instruments (rotary evaporators, fermentation tanks, chemical reactors, freeze-drying equipments, pharmaceutical reactors, etc.);
(5)Bigger cooling capacity and faster cooling speed, which have greatly improved the working efficiency;
(6)It can effectively ensure the normal use of all kinds of precision instruments under the working conditions such as lacking water, the poor quality,pressure and temperature of water, and high temperature;
(7)The flow of circulating pump can be either adjusted or customized, which has greatly met the actual needs of different customers;
(8) All models of this machine can be matched reasonably between the low temperature and the cooling capacity or capacity basing on the requirements of customers.
Zhengzhou Keda Machinery and Instrument Equipmnet Co.,Ltd. is specialized in P&D,production .
Our products are popular in home and abroad,and widely praised.

We are specialized in Low temperature circulating pump and other chemical equipment .If there are anything I can help ,please be free to contact me .
