Help CenterWaste Tyre/tire/plastic Pyrolysis to Diesel and Petrol
Related Products
-
HIGHEST PROFIT!!!used Tyre Recycling MachineUS$ 40,000 - 70,000MOQ: 1 Set -
HIGHEST PROFIT!!!scrap Tire Recycling MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
the 5th Generation CE and ISO Abs Plastic RecyclingUS$ 40,000 - 70,000MOQ: 1 Set
-
Aquiring CE Certification 8 Ton Q345R Waste Rubber Pyrolysis MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
Batch Distillation to Diesel Can be Used for Diesel CarUS$ 40,000 - 70,000MOQ: 1 Set
Specifications
1.plastic pyrolysis2.ISO&CE
3.the best seller plastic pyrolysis
4.long life plastic pyrolysis
5.Newest plastic pyrolysis
We have three factories totally.One is demo factory for showing our running machine lines to customers;One is our big workshop;And the other one is our oldest factory which our boss refined oil by himself since 1993.And we also have our own laboratory.
Features of plastic pyrolysis
Reactor directly decides the machine's safety and service life. It is made by welded steel plate. So the quality of welding will have a direct impact on safety and service life. Therefore, we use automatic welding machine, X rays detection and heating treatment which will not only guarantee the quality of welding but also greatly improve working efficiency.
Cooling system
Cooling systems decides oil output. There are two steps for cooling. Cooling pipe is the first step. The second is condenser. We have three condensers. And there are 57 pipes in one condenser. Diameter is 48mm for one small pipe. The heat exchanging area is about 13square meters for one condenser. So the total cooling area is about 40 square meters, which will guarantee you a high oil yield.
Main features :
Safety:
1. Professional sealing technology for cover, oil outlet.
2. Heavy oil is separated which can avoid the problems of jam in later condensing.
3. Vacuum system will prevent exhaust gas from going back to reactor and causing accident.
4. Alarm, safety valves, pressure gauge and a special anti-blocking device
5.It is dangerous to buning exhaust gas(C1 to C4) . In our process, it is transferred first through the safety device and a safety burning air muzzle. Before burning, we should ensure the safety of production.
Environment friendly:
1.Well water dedusting system with high pressure nozzle and environmental damper inside can avoid black smoke.
2.The exhaust gas will be directly recycled for heating reactor, no gas pollution
3.Every junction of the reactor is in good sealing situation with professional sealing material.
Long service life :
1.Material: Q245R special steel plate ,thickness 14mm,16mm,18mm,20mm.
2.The service life of the reactor will be 3-5 years
Energy saving:
1. The special design of fire chimney can be more efficiency.
2. The exhaust gas will be recycled for reactor heating .
Specification plastic pyrolysis:
No. |
Items |
contents |
||
1 |
Model |
HY-6T |
HY-8T |
HY-10T |
2 |
Raw Material |
Tire/Plastic |
Tire/Plastic |
Tire/Plastic |
3 |
Size of Reactor |
D2200mm*L6000mm |
D2600mm*L6000mm |
D2800mm*L6000mm |
4 |
Diameter Size of Feeding |
720mm/1200mm |
720mm/1200mm |
720mm/1200mm |
5 |
Material of Reactor |
Q245 Rboiler plate |
Q245 Rboiler plate |
Q245 Rboiler plate |
6 |
Thickness of Reactor |
12/14/16/18mm |
12/14/16/18mm |
12/14/16/18mm |
7 |
24-hour Capacity |
6 ton |
8 ton |
10 ton |
