Specifications
1.Waste rubber pyrolysis machine2.Waste rubber pyrolysis machine to fuel oil
3.Waste rubber pyrolysis machine
5.ISO&CE
Depending on reasonable structure, reliable quality and excellent performance, our waste plastic/tires/oil refining equipments achieve wide recognition from customers and become a well-known brand.
Safety
1) Pressure gauge, alarming device, safe valve.
2) We have anti-clogging device, in case of jam, there will be antomatic alaiming, automatic exhaust and automatic decompression.
3) Using 245R/345R boiler plate or 204/205 stainless. The thickness of part by fire is 14/16/18mm, other parts is 12mm.
4) Automatic welding, processing according to standard of head of pressure vessel.
5) With proprietary vacuum system, it is much safer on condition of negative pressure.
Energy saving
1) Exhaust gas recycle to furnace.
2) Continuous feeding with automatic feeder, no gas leak.
Environmental protection
1) Built-in slagging, seal with water, no solid pollution.
2) With dust removal equipment there is no air pollution.
Waste rubber pyrolysis machine Working process
1) Waste plastic refinning flow: plastic separation → automatic feed → catalytic cracking→ oil-water separation → cooling liquid → crude oil → flammable gas recovery → flammable gas combustion → desufuration and dust removal
2) Waste tires refining flow: tire broken → automatic feed → catalytic cracking → oil-water separation → cooling liquid → carbon black emission → carbon black processing → crude oil → flammable gas recovery → flammable gas combustion → desulfuration removal
Technical parameter
Items |
Contents |
||
Raw material |
Waste tyres, scrap plastic, waste rubber |
||
Structure form |
Horizontal |
||
Model |
HY-6T |
HY-8T |
HY-10T |
Size of reactor |
D2200mm*L6000mm |
D2200mm*L6600mm |
D2600mm*L6600mm |
24-hour capacity |
6 tones |
8 tones |
10 tones |
Operating pressure |
Constant pressure |
||
Heating material |
Coal, charcoal, fuel gas, fuel oil |
||
Average out-put oil rate |
40%-45% |
||
Material of reactor |
245R/345R boiler plate |
||
Thickness of reactor |
12/14/16/18mm |
||
Rotate speed of reactor |
0.8 turn/minute |
||
Mode of cooling |
Water cooling |
||
Working mode |
Continuous feeding |
||
Delivery time |
30 days after receiving deposit |
||
Payment term |
T/T, 30% in advance, balance paid before shipment |
||
