Specifications
1.scrap tire recycling machine2.ISO&CE
3.the best seller scrap tire recycling machine
4.long life scrap tire recycling
Contact Lily Ma:0086-13733870203
A---The host of scrap tire recycling machine
is composed by reactor,fire channel,outer packaging,slag discharge mouth and etc.
1.Reactor---Pyrolysis waste tyre/rubber/plastic.Build-in spiral plate,which is convenient for automatically feeding and slagging.
2.Fire channel---Composed by several furnaces,which is high utilization rate and energy saving.
3.Outer packaging---Adopting several layers of refractory material inside.Be made of steel plate outside which is solid,good looking and sealing well.
4.Slag discharge mouth---Is used for automatically slagging.
B---Catalyst chamber---Reduce the speed of oil gas.
1.It has 3 functions:1)catalysis.2)dust removing, with the special design, the dust will sink, and the gas get through, avoid congestion.3)decompress.
2.In addition,our factory has the specific catalyst which can speed up the pyrolysis speed and improve the oil
Yield.
C---Oil-water separator---separate oil gas and water; first water closing for safety.
This device,it can avoid the gas go back to the furnace.
Not too long ago, there are explosions occur in India, it is because the gas go back to the furnace caused.But with this special device, it can avoid the gas go back to the furnace and then avoid blast.
D---Specification diameter of scrap tire recycling machine
Model |
HY-10 |
HY-8 |
HY-7 |
HY-6 |
Reactor size |
D2800*L6000mm |
D2600*L6000mm |
D2200*L6600mm |
D2200*L6000mm |
Dimension |
36.93m³ |
31.84m³ |
25.08m3 |
22.80m³ |
Thickness of reactor |
14/16/18mm |
|||
Rotate speed of reactor |
0.8 turn/minute |
|||
Driving method |
Gear drive |
|||
Floor space |
250square meter |
|||
Total power |
20Kw |
|||
