Semi Automatic Flat Die Creasing Machine

Semi Automatic Flat Die Creasing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Die-cutting Machine
Computerized:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Die-cutting Machine
Computerized Yes
Place of Origin Zhejiang, China
Brand Name Tonghe
Model Number TH 1300BMY
Voltage 380V
Power(W) 13500
Dimension(L*W*H) 3350*2350*2280mm
Weight 14T
Certification CE/ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Use

This machine is mainly used for the diecutting, creasing, cold and hot embossing of cigarette box, drug box, wine box and label in the packing and decorating industries.

The machine combines several advantages over many other die cutters both at home and abroad.

Gripper bars with high intensity are applicable to all kinds of cardboard, paperboard and corrugated

paper. Frontal, back and side registration mechanism ensures great precision of die cutting. Other

parts are adopted such as intermittent mechanism with high precision, air clutch, pneumatic locking

mechanism, programmable controller and man-machine interface. The interface can display various

digital information of machine such as working speed, total running time etc. It is easy to eliminate

troubles according to the display of trouble shooting. Transducer is adopted to control the main motor

in achieving stepless speed variation. The machine has a lot of sensors and safe-ensuring devices

to guarantee the safety to operator and the environment. Frontal and back pressure can be adjusted

separately. It is convenient to stop the machine by hand. It can also realize die cutting without clipper

margin.

Technical parameters

Max.paper size (mm)

1310*960

Min.paper size(mm)

550*500

Max.cutting size (mm)

1290*950

Pressure(T)

300

Max.cutting speed (s/h)

4500

Diecutting precision

0.1mm

Sheet thickness (mm)

200-2000g/m2(cardboard)/less then 8mm thickness (corrugated board)

Total power (KW)

13.5

Net weight (T)

14

Overall dimension (mm)

3350*2350*2280
