Help CenterOne Roll A4 Paper Sheeting Cutter Machine
Related Products
-
Fully Automatic UV Varnish Laminating Machine/Automatic UV Sheet Varnish MachineNegotiableMOQ: 1 Set -
High Speed Automatic PP Sheets Punching MachineNegotiableMOQ: 1 Set
-
ML750 Semiautomatic Hand Fed Die Cutting Creasing MachineNegotiableMOQ: 1 Set
-
80*110 Semiautomatic Flat Paper Box Sheet Die Cutting MachineNegotiableMOQ: 1 Set
-
Sheet Fed Creasing Cutting Machine For Paperboard Plastic LeatherNegotiableMOQ: 1 Set
This high precision computer controlled vertical & horizontal cutting machine has the highest precision that can be instead of foreign machines. It is the best choose among the manufactures who produce medium or high level products. This machine is suitable for cutting the large coil packaging material(such as gloss photo-paper, digital photo paper,ordinary paper, coated paper, board paper, gold or silver cardboard, holographic paper, cigarettes & wines-packing and printing material .etc) , paper & plastic complex material and fiber material,etc.
Features
1.This machine adopts the servo motor (or step-less motor)to control the fixed-length cutting, feeding.It is equipped with the photoelectric, Correction, tracing modifying system. It can do crosscutting and Vertical cutting at the same time.And it can trace feeding institution with the products,blowing& absorbing transportation at same time, automatic collecting, Robert automatic folding materials and cross transport to worktable.
2.Drive System use pneumatic system, Photoelectric sensor to control, folding materials system use oil pressure to improve equipment..This machine integrates photoelectric,liquid and gas as a whole, PLC touching screen, and has the features of easy operation high-precision cutting state operation and low noise.
3.The machine has the features of the motor frequency speed adjustment, automation counting, giving an alarm when stop and tension with digital indication.
4.All transitional rollers can be done in clients opinions to avoid surface injure.
5.This machine is very important to scratch of gloss photo paper.
Cutting Size |
A4(210*297) |
|
Size Precision |
±0.2MM |
|
The accuracy |
±0.2MM |
|
Trimness (20-100pcs) |
Width(Vertical Cutting Precision) |
±0.15MM |
Length(Crosscutting Precision) |
±0.2MM(fixed-length) |
|
maximum Width of raw materials |
1300MM |
|
maximum diameter of raw materials |
1200MM(Max.weight:8ton) |
|
Speed |
120cut/min |
|
Max.Stack Height |
30MM |
|
Paper tube core Inner Dia. |
3'=76.2MM |
|
source of air pressure |
0.4-0.6Mpa |
|
Work Voltage |
380V |
|
Total Power |
13kw(Except air pressure power:11kw,1.6m2 ) |
|
Weight |
3.5ton |
|
