DC-DC Boost Converter Module Power Adjustable Liter 12V 48V High-current High-efficiency DC-liter 60V Adjustable

Product Name: DC-DC boost converter module power adjustable liter 12V 48V high-current high-efficiency DC-liter 60V adjustable
Product Type: FULREE B1660
Color classification:
Product details: Module Properties: non-isolated boost module (BOOST)
Input voltage: 10-32V
Output voltage: continuously adjustable (36-60V)
Output Current: 5A (MAX)
Input Current: 16A (MAX) (more than 10A, please enhance heat dissipation,)
Output power: natural cooling 82W (MAX), enhance heat dissipation 120W (MAX)
Output Ripple: 2% (MAX) 20M bandwidth
Operating temperature: Industrial grade (-40 ℃ to + 85 ℃) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation)
Full temperature: 45 ℃
No-load current: Typical 25mA
Voltage Regulation: ± 0.5%
Dynamic response speed: 5% 200uS
Short circuit protection: None (Please enter the installation of fuses or circuit protection)
Input reverse polarity protection: no, you can enter the series diode.
Connection: solderless terminal
Positive input IN +, IN- input negative, OUT + Output +, OUT- output negative.

Volume Specifications:

65 (L) * 47 (W) * 23.5 (H) mm

Note:
1. Within one meter lead wire length not less than 1.5 square feet, if greater than 1 m length wire, bold, recommended 2.5 to 4 square feet of line is better
2. The module operates at high power, high temperature, plus time to install the fan housing, low power without adding a fan, be sure the module heat sink temperature should not exceed 80 degrees.
3. Using the input can not be reversed output can not be shorted.
4.12V battery discharge voltage can not be lower than 10.5V, Li-ion battery used in tandem (single 3.7V) discharge voltage can not be lower than 2.7V.

Applications:

Applications

1.DIY an output adjustable vehicle power supply, only need to enter access your 12V power supply, the output voltage you can (35-60V) on freedom of continuous adjustment, but the output voltage can not be lower than the input voltage, oh.

2. Boost charger, you can use the 12V power supply is higher than 12V battery charging, such as 48V battery.

3. The power supply for your electronic device, as long as the voltage is adjusted to the voltage you need and the current does not exceed the rated current is able to work properly.

The solar battery charging for electric vehicles
