Woodworking Rotary Lathe
US$ 8,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HAIYONG
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shandong, China
Brand Name
HAIYONG
Model Number
BXQ1815
Voltage
380/220V
Power(W)
19.75
Weight
3500
Dimension(L*W*H)
3320*1800*1260
Certification
ISO9001
Warranty
One Year
After-sales Service Provided
Overseas service center available
This machine is the main machine in the plywood producing.it can peeling less than Φ360mm log-core.the same log-core can be changed the clearance between knives by picture guide system. it can peel table plate and core plate.it has a high efficiency,and a high rate of wood usage.it is fit for the plywood company for efficient producing.
Technical Specification:
Model | HX1815 | HX1822 | HX1827 |
Max cutting length (mm) | 1350 | 2000 | 2600 |
Max cutting diameter (mm) | Φ300 | Φ300 | Φ300 |
Log-core diameter (mm) | Φ26 | Φ26 | Φ26 |
Cutting thickness (mm) | 0.8-3.0 | 0.8-3.0 | 0.8-3.0 |
Veneer output speed (m/min) | 42 | 42 | 42 |
Power (kw) | 19.75 | 21.75 | 25.75 |
Overall dimension (mm) | 3320*1800*1260 | 3700*1800*1490 | 4585*1800*1560 |
N.W (kg) | 3500 | 5500 | 7000 |
