Specifications
Oil Refinery1.90% oil yield
2.long life maintenance
3.with CE, SGS, ISO
4.high efficiency cooling condensers
Waste Tyre Oil Refinery Equipment with 90% Oil Yield
A.The main parts of distillation machine
a)Distillation chamber
b)Distillation column
c)Sync gas recycling system
d)Condensers
e)Oil tanks
f)Heat exchanger
g)Burning room
B.XY-8 Oil Refinery Equipment Specification
NO |
ITEM |
PROJECT |
1 |
Suitable raw materials |
Waste engine oil, pyrolysis fuel oil, crude oil
|
2 |
Structure |
Horizontal type
|
3 |
Capacity(24 hours) |
3.5~6.5 tons
|
4 |
Work pressure |
Normal pressure |
5 |
Oil yield |
85%-95%
|
6 |
Power |
12KWH
|
7 |
Cooling method |
Cycle water
|
8 |
Condensers |
4 pieces of vertical condensers |
9 |
Emission treatment |
New de-sulfurization smoke scrubbers
|
10 |
Heating method |
Hot air
|
11 |
Type of installation |
With foundation
|
12 |
Noise dB (A) |
Less than 85
|
13 |
Dimension of reactor |
2200*6000mm/2500*8800mm
|
14 |
Operating mode |
Semi-continuous operation
|
15 |
Main chamber weight |
10-13 tons
|
16 |
Total weight |
25-35 tons
|
17 |
Installation space required |
35m*15mm
|
18 |
End product |
Non-standard diesel oil
|
19 |
Manpower |
1~2/shift
|
20 |
Shipment requirement |
1*40HC+1*40FR
|
C. The features of oil refinery euipment
a:Adopting automatic submerged-arc welding technology
b:All of the weldings will be detected by the ultrasonic nondestructive testing method to ensure the welding quality and the welding shape.
c:Adoptingmanufacture process controlling system on the quality, every manufacture process, manufacture date, etc.
d:Equipped with antiexplosion device, safety valves, emergency valves, pressure and temperature meters, as well as the alarming system.
2> Environmental-friendly:
a: Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke
b:Smell during operation: Fully enclosed during the operation
D. The raw materials and end products
Tire oil after distillaton
Plastic oil before and after distillation
Engine oil before and after distillation
E. Jinyuan Certifications
1.Quality warranty period: One year warranty for the main reactor of pyrolysis machines and lifetime maintenance for complete set of machines.
2.Our company sends engineers for installation and commissioning in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.
3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the buyer.
4. For the damage caused by the users, our company provides the parts and accessories with cost price.
5. Our factory supplies the wearing parts with the cost price to clients.
General introduction
ShangQiu Jinyuan Machiney Equipment Co.,Ltd, as the first demostic professional institute in the recycling and ultilization of solid waste (waste tyre,plastic,rubbers) is a technology innovative demonstration enterprise involving scienfic research ,development ,manufacture and sales together.
