Grinding Ball Mill High Quality Coarse Grinding Mill Workload 10 t/h
Product Description
Product use
Coarse Grinding Mill widely used in metallurgy, mining,chemical, cement, coal, dry stone, feldspar, quartz stone, construction, sand, refractories, and ceramic industrial and mining enterprise, engaged in breaking and crushing the material in the operation. It is mainly suitable for crushing compression strength not higher than 320MPA of various soft and hard ore.
Product features
1.The production capacity, high crushing ratio.
2.Low power consumption, uniform particle size.
3.Mechanical structure is simple, compact and lightweight.
4.Low investment costs, management and convenient.
Structure and working principle
Coarse Grinding Mill mainly by coarse grinding casing, rotor, bearing the hammer and the grate bars and other component. Upper and lower case in two parts, wedded together by a steel plate after cutting, the remaining parts bolted into one. Set with high manganese steel liner inside the case, to facilitate replacement of worn; It array of rules installed on the spindle distribution of the hammer, hammer and rotary table and through the rotor shaft formed. Host through the motor, V-belt driven spindle, so that the rotor rotates, hammer by the centrifugal force generated by rotation around the stretch to, bulk materials from the feed inlet into the crushing chamber, the high speed movement of the hammer will be crushed. Broken by passing the material under.
Coarse Grinding Mill parameters
Model |
PC4008-75 |
PC4012-90 |
PC4015-132 |
Rotor diameter (mm) |
750 |
900 |
1150 |
Rotor length (r/mm) |
800 |
1200 |
1500 |
Rotor speed(r/min) |
800-1000 |
800-1000 |
550-800 |
Reed heed size(mm) |
320x930 |
400x1200 |
500x1500 |
Max feed size(mm) |
<50 |
<50 |
<100 |
Fineness(mm) |
0-3 |
0-3 |
0-8 |
Processing(t/h) |
10-30 |
30-60 |
60-100 |
Motor power(kw) |
55-75 |
75-90 |
110-132 |
The number of hammer |
18 |
32 |
32 |
Dimension(L*W*H/mm) |
2310x1665x1610 |
2840x2100x2020 |
3720x2650x2540 |
