Hot Plate for Laboratory/magnetic Hot Plate/table Top Hot Plate

Name: Hot Plate for Laboratory/magnetic Hot Plate/table Top Hot Plate
Brand: KINGDAK
SKU: 141460322
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

KINGDAK

Model Number:

KNJR-B1 series/KTWJR-B1 series

Place of Origin:

Shanghai, China

Shanghai Kingdak Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Brand Name KINGDAK

Model Number KNJR-B1 series/KTWJR-B1 series

Place of Origin Shanghai, China

Laboratory Intelligent Digital Display Ceramic Top Square Hot Plate

Main Feature :

1. Heat Plate material : black Ceramic material

2. Top Dimension : 140 x 140mm, 180 x 180mm , 230 x 230 mm,280 x 280mm

3. Temperature Range : Ambient to 380 °C

4. Heat Capacity for Beaker : 50ML - 15 l

5. Temperature Control : PID , Inner and outer Thermocouple

Technical specifications:

Parameter KNJRB1 series

Model	KNJRB1140	KNJRB1180	KNJRB1230	KNJRB1280
Top Plate Dimension (mm)	140 × 140	180 × 180	230 × 230	280 × 280
Heating Temperature Range (°C )	Ambient to 380	Ambient to380	Ambient to 380	Ambient to 380
Heat Control	PID Control . Inner and Outer Temperature sensor ,LED Display
Fixed Safety Circuit	380°C
Permissible Ambient Temperature	Ambient Temperature to 40°C
Top Material	Superfine Ceramic
Voltage	220v ,50Hz / 110V ,60Hz
Power(w)	260	350	600	750
Motor Power	8W, DC14V	8W, DC14V	40W, DC20V	40W, DC20V
Temperature Accuracy (°C )	±1°C
Stirring Flask Capacity(ml)	50-500	50-2000	50-5000	50-10000
Overall Dimensions (mm) ( L × W × H )	265 ×155 × 120	325 × 215 ×120	430 × 270 × 150	500 × 330 × 150
Packing Dimension (mm)	315 × 205 ×170	375 × 265 ×170	480 × 320 × 200	550 × 380 × 200
Shipping Weight (kg)	2.2±0.2	4±0.2	7±0.2	9.5±0.2
Working time	Continue
Shell Material	Superfine Metal

Parameter KTWJRB1 series

Model	KTWJRB1140	KTWJRB1180	KTWJRB1230	KTWJRB1280
Top Plate Dimension (mm)	140 × 140	180 × 180	230 × 230	280 × 280
Heating Temperature Range (°C )	Ambient to 380	Ambient to380	Ambient to 380	Ambient to 380
Heat Control	PID Control .
Fixed Safety Circuit	380°C
Permissible Ambient Temperature	Ambient Temperature to 40°C
Top Material	Superfine Ceramic
Voltage	220v ,50Hz / 110 v,60Hz
Power(w)	260	350	600	750
Motor Power	8W, DC14V	8W, DC14V	40W, DC20V	40W, DC20V
Temperature Accuracy (°C )	±3°C
Stirring Flask Capacity(ml)	50-500	50-2000	50-5000	50-10000
Overall Dimensions (mm) ( L × W × H )	265 ×155 × 120	325 × 215 ×120	430 × 270 × 150	500 × 330 × 150
Packing Dimension (mm)	315 × 205 ×170	375 × 265 ×170	480 × 320 × 200	550 × 380 × 200
Shipping Weight (kg)	2.2±0.2	4±0.2	7±0.2	9.5±0.2
Working time	Continue
Shell Material	Superfine Metal
