KNCL-BS intelligent lab magnetic heating stirrer
features of the lab magnetic heating stirrer:
1..Adopt the square TU2 red copper plate which is processed by Vacuum coating to heat ,with beautiful appearance and anticorrosion ,without deformation when get heated.
2.Special heating mode (patent applied for ),the sufface maxmium temperature can be up to 360°C.
3.speed digital displayed.
4.Temperature controll adopts uzzy PID control algorithm ,with double screen digital display , self adjustment function ,high precision ,small temperature difference , onbutton tick operating ,use inner and outer thermocouples to measure temperature , controlled silicon manage the output ,160 to240V wide voltage power supply and with Broken accidentally protection function.
5.Can heat the standard and off-standard 50-1000ml reaction –bulbs and other canisters which contain no magnetic metal .
6.Using DC brushless speed regulation motor , stable performance , low noise , long service life , no spark.
7.The shell adopts one time forming flame retardant strengthen PBT injection moulding shell, with thermostability,anti-corrosion and good insulation property.
8.With overtemperature protection function.
9.30 ° cant control panel is suitable for standing and sitting viewing angle .
10.Stepless speed adjustment,low speed-stable , high speed-strong
technical parameter
1.power supply:~220∨,50Hz
2.material of plate:TU2 red copper
3.range of speed adjustment:50-1800rotation /minute stepless adjustment ,digital display
3.power of motor:40w ,DC 14-24V
4.capacity of stirring:50-10000ml
5.power of heating :260-750W
6.accuracy of temperature controlling:±1°C
7.temperature controlling mode:intelligent digital display , controlled silicon controlling ,inner and outer temperature sensor
8.heating temperature :surface temperature can be up to 350°C
9.boiling time :water 10-25 minutes
10.heating wire :Cr20Ni80
11.heating area:140*140 180*180 230*230 280*280mm
ing time :continous
13.fuse pipe:ø5×20 15A
