Black Pepper Processing Equipment

Black Pepper Processing Equipment photo-1
Black Pepper Processing Equipment photo-2
Black Pepper Processing Equipment photo-3
Black Pepper Processing Equipment photo-4
Black Pepper Processing Equipment photo-5
Black Pepper Processing Equipment photo-6
US$ 50,000 - 500,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GUANFENG
Model Number:
GPL-PP
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name GUANFENG
Model Number GPL-PP
Type Other, pepper processing line, Continuous processing line
After-sales Service Provided Engineers available to service machinery overseas

Black pepper processing equipment



Main Application: This processing line is mainly used for pretreatment processing for green pepper and similar agri-food products;

Capacity: from 500-3000kg/hr for fresh materials;

Main processing flow:

The processing have the complete processing flows include:



1. washing --> 2. blanching --> 3. cooling --> 4. soaking --> 5. drying.



Description:



Washing: bubble washing with high pressure spray.



Blanching: belt type continuous blanching in boiling water.



Cooling: with bubble water and spray.





Main equipments:

Black pepper processing equipment



#Equipment NameDescriptionQty.
 1  Feeding conveyor  Loading peppers to the processing line
 2  Bubble washing machine  Bubble washing and cleaning 1
 3  Belt blancher  Blanching or pre-cooking 1
 4  Water chilling machine  Cooling after blanching 1
 5  Elevating conveyor Elevating and feeding the soaking tank 1
 6  Soaking tank with elevating conveying belt  Soaking to soften the skin 2
 7  Vibration draining machine  Remove surface water before drying 1
  8  Stainless steel material trolleys  Transporation of pepper 5
 9  GTJ Bin type drying machine Hot air dehydration 10



Black pepper processing equipment Black pepper processing equipment



Services provided by us:

The following equipment and services provided by supplier:

1)   Working flow layout of equipment supplied by our company

2)   Plant layout of equipment supplied by our company

3)   Layout drawing for related pipe lines

4)   Electrical wires from control cabinet to connect with equipment

5)   Packing for equipment and domestic transportation in China

6)   Equipment and guide for installation and commissioning

7)   Operation manual of equipment

8)   Training for operation personnel

9)  Consultant for processing technology







Packaging & Shipping

Seaworthy packing with steel frame for big machienry. Wooden or plywood carton packing for accessories and fittings.

Black pepper processing equipment




Our Services

1) Food processing technology consultency;

2) Working flow layout design;

3) Plant layout for processing line equipments;

4) Onsite guide of installation and commissioning;

5) Training for local operators;

6) After sales technical support.









Company Information

GUANFENG MACHINERY is located in the Yangtze River delta, Shangyu city, Zhejiang province with the most convenient transportation and prosperous economic in China, 1 hour by car to Hangzhou or Ningbo and 2 hours from Shanghai.



Our company was established by a group of experienced and dedicated engineers who are excited and specialized in finding the best solutions to improve the food processing equipments therefore bring value to the food processors and make better quality food products. Based on the market demands and our technology background, we focus on the developing and manufacturing equipments for IQF frozen food industry, vegetables and fruits dehydration, Freeze drying (FD), and food processing lines for various vegetables, fruits and seafood industry.



We value "honesty, innovative and quality" because we know that we are not only supplying equipment to our clients but the partners to help our clients to get a better result. Keeping this in our mind, we not only make high quality food processing equipment, but also help the clients to figure out the optimum processing work flows, make amendments according to client's specific needs, training staffs for the user of our equipment and even more, because we believe that our users or clients' success is the foundation of ours.



Are you looking for the equipment for your next project? Why not just send us an email!






Black pepper processing equipment                          Black pepper processing equipment



Black pepper processing equipment
