Help CenterHigh Production Efficiency Glass Fiber Reinforced Plastic Spiral Chute
Related Products
-
Hydraulic Cyclone/spiral Classifier /screw Classifier With Hot SaleUS$ 2,222 - 333,333MOQ: 1 Set -
High Classification Efficiency Hydro-clone/Hydro-cyclone Separator/Mining Hydro-cyclone/Hydro Cyclone BoxUS$ 100 - 1,000MOQ: 1 Set
-
Sizer/ClassifierUS$ 918 - 91,800MOQ: 1 Set
-
Rake ClassifierUS$ 1,180 - 11,800MOQ: 1 Set
-
Screw FeederUS$ 1,180 - 11,800MOQ: 1 Set
Specifications
1.Large capacity2.Convenient Operation
3.Certificated by ISO9001:2008
4.Wonderful and practical economical
5.Best performan
Product Name: Spiral Chute
Spiral Chute is Beijing BGRIMM successful research has the domestic advanced level of high-performance re-election of new equipment for particle size sorting of 0.3 - 0.05 fine-grained iron, tin, tungsten, tantalum, niobium, gold, coal mine , monazite,
Details: Glass Steel Spiral Chute is Beijing BGRIMM successful research has the domestic advanced level of high-performance re-election of new equipment for particle size sorting of 0.3 - 0.05 fine-grained iron, tin, tungsten, tantalum, niobium, gold, coal, monazite, rutile, zircon, as well as the proportion of the poor have enough other metal or non-metallic.
Model | BLL-1200 | BLL-900 | BLL-600 | BLL-400 | |
Diameter (mm) | 1200 | 900 | 600 | 400 | |
Screw diameter (mm) | 900,720,540 | 675,540,405 | 450,360,270 | 240,180 | |
From the diameter ratio (pitch / diameter) | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.6,0.45 | |
Horizontal Inclination (degrees) | 90 | 90 | 90 | 90 | |
Installation of each screw head up to the number of | 4 | 3 | 2 | 2 | |
To the ore particle size (mm) | 0.3-0.03 | 0.3-0.03 | 0.2-0.02 | 0.2-0.02 | |
To the ore concentration (%) | 25-55 | 25-55 | 25-55 | 25-55 | |
Production capacity (t / h) | 4-6 | 2-3 | 0.8-1.2 | 0.15-0.2 | |
Dimensions | Length (mm) | 1360 | 1060 | 700 | 460 |
Width (mm) | 1360 | 1060 | 700 | 460 | |
Height (mm) | 5230 | 4000 | 2600 | 1500 | |
Weight (kg) | 600 | 400 | 150 | 50 | |
