Help CenterHigh Classification Efficiency Hydro-clone/Hydro-cyclone Separator/Mining Hydro-cyclone/Hydro Cyclone Box
Related Products
Specifications
1.High Classification Efficiency2.Advanced technology
3. Environmental Protection Experimental
4.Wonderful and practical eco
FX-type hydrocy clone is frequently used in the second paragraph of the metal concentrator mill or coarse ore in the grinding process and mechanical grading machine into a closed-circuit use, made to replace the machine seized grading machine, security and grain size grading operation. The device has a simple structure, long life, large capacity, small footprint, non-consumption of power and so on. Is a highly efficient micro-fine particles grading, de-mud equipment. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
The device is suitable for laboratory tests during the coal preparation overflow dressing classification, concentration, de-mud, dehydration.
Model |
Uite | FX 25 | FX 50 | FX 75 | FX 100 |
Diameter | mm | 25 | 50 | 75 | 100 |
Feed pressure | MPA | 0.1-0.5 | 0.1-0.4 | 0.1-0.4 | 0.06-0.35 |
Cone angle | o | 20 | 20 | 20 | 20 |
Particie size of overflow | mm | 0.2 | 0.3 | 0.6 | 1 |
Particie size of overflow | um | 2-10 | 10-74 | 20-74 | 20-100 |
Overflow size | Mm | 6 | 8, 12 | 10,14 | 20,30 |
Output size | Mm | 2.5-4 | 5-6 | 6-8 | 14-30 |
Capacity | m3/h | 0.3-1 | 1-2 | 2-5 | 5-12 |
Overall dimensions | mm | 160/152/387 | 160/155/590 | 240/230/465 | 260/210/520 |
Weighe | kg | 1 | 2 | 4 | 8 |
