Specifications
1. Good performance with a conversion rate of big, strong vibration2. Screening effective
3. Easy to use and flexible jacket
Primarily for coal, electricity, mining, geological, chemical, metallurgy, building materials and chemical industries and scientific research units, institutions screening laboratory analysis of materials. Is the alternative to manual hand sieves sieving, reducing operator labor intensity, the electrical control of an electronic counting controller, so that screening test is expected to be accurate within the screening times.
Laboratory test sieve shaker advanced structure, good performance with a conversion rate of big, strong vibration, easy to use, screening effective, easy to use and flexible jacket and so on.
Machine equipped with 200 standard sieve, sieve shaking frequency of 221 beats / min, the vibration hit number 147 beats / min
Model | SDB-200 | |
Unit | Figure | |
Sieve diameter | mm | 300 200 |
Sieves stacked high | mm | 440 |
Screen amplitude | mm | 8 |
Number of sieve shaker | /min | 221 |
Number of jar | /min | 147 |
turning radius | mm | 12.5 |
power | kw | 0.37 |
Overall dimensions | mm | 600*400*880 |
Screen frame size | mm | 200 |
screen size | mm | 20-200 |
Feed size | mm | 0.5 |
Screen Layers | storey | 8 |
Weight | kg | 130 |
