ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599
Technical Parameter of laboratory Vertical Sand Pump
DL-5, XTLZ-type multi-disc vacuum filter used in geological, metallurgical, coal, building materials, mines, schools, scientific research and experiments to carry out mineral optional units in the experimental work, as a flotation, re-election, magnetic and other operations After dehydration, test sample, solid-liquid separation. Machine mainly by the vacuum pump, Manifold air filter device, vacuum tank, and two filter disk group or its drainage through controlled automatic drainage, to achieve the purpose of solid-liquid separation. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
The device is a kind of filter can be intermittent or continuous laboratory-type filtration equipment can be used as product dehydration, the use of solid-liquid separation, simple structure, operation, convenient maintenance, filtering effects of high adaptability, for difficult to filter and concentration of minerals lower pulp filtration, the effect is most remarkable.
Model | Uite | DL-5C 240/120 | XTLZ 260/200 |
Disc diameter | mm | grail 240 pannikin 120 | grail 260 pannikin 200 |
Vaccum pressure | KPA | 91.2 | 80 |
Pulp solid-liquid ratio |
| 1(4-7) | 1(4-7) |
Feed size | mm | 0.5 | 0.5 |
Dry material capa | g | 500 | 600 |
Filter time | min | 1-10 | 1-10 |
Output water time | s | 30 | 30 |
Cake moisture | % | 20 | 20 |
Voltage | v | 380 | 380 |
power | kw | 1.6 | 1.5 |
Overall dimensions | mm | 1030/420/970 | 6500/5400/1140 |
Weighe | kg | 160 | 200 |
