Flotation Seprating Process
- 1000 Set / Sets per Month
- XiaMen/GuangZhou
- T/T
You May Like
Product Details
| Condition | New | Type | Flotation Separator | |
| Place of Origin | Jiangxi, China | Brand Name | oasis | |
| Model Number | other | Certification | ISO9001:2008 |
Product Description
ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599 is production
It uses in classifying in non-ferrous and ferrous metal mineral. SF is the mechanical agitation type. It can own draw the inspiration and the pulp; Compared to A, its spirit is big, and the power loss low, and the impeller lap wears lightly; JIF has the self-absorption ability, the suction intensity big, and it may adjust the air input in 0.1 m3/min -1m3/min; the impeller diameter is small, the rotational speed low, consuming electricity little, and also be advantageous for the automatic control.
Its features are as follows:
(1)The capacity of air suction is large, the power consumption is low.
(2)Every stand has three functions of air suction, slurry suction and floatation simultaneously being unique in floatation return circuit without need for any supplementary equipment, the circuit change is convenient for horizontal location.
(3)The slurry cycle is rational, the settlement of coarse sand can be reduced into full play.
(4)The regulation is convenient to equip auto and electro-controlling arrangements for slutty level.
Model | Impeller Diameter (mm) | Impeller Rotational (r/min) | Productive Capacity (m /min) | Motor | Motor | Dimension (mm) | ||
Model | Power (KW) | Model | Power (KW) | |||||
SF-0.15 | 200 | 536 | 0.05-0.18 | Y100L-6 | 1.5 | Y80L-4 | 0.55 | 500*500*600 |
SF-0.37 | 296 | 386 | 0.2-0.4 | Y90L-4 | 1.5 | Y80L-4 | 0.55 | 700*700*750 |
SF-1.2 | 450 | 312 | 0.6-1.2 | Y32M-6 | 5.5 | 90SL-4 | 1.1 | 1100*1100*1100 |
SF-2.8 | 550 | 268 | 1.5-3.5 | Y180L-6 | 11 | Y100L-6 | 1.5 | 1700*1600*1150 |
SF-4 | 650 | 220 | 2-4 | Y200L-8 | 15 | Y100L-6 | 1.5 | 1850*2050*1200 |
SF-8 | 760 | 191 | 4-8 | Y250M-8 | 30 | Y100L-6 | 1.5 | 2200*2900*1400 |
SF-10 | 760 | 191 | 5-10 | Y250M-8 | 30 | Y100L-6 | 1.5 | 2200*2900*1700 |
