Help CenterLab Disc Vacuum Filter for Gold Mineral Equipment
Related Products
Feature
1.Widely used
2. Filtering effects of high adaptability
3. Simple structure,
4. Easy operation
5. Energy conservation and environment protection
6. All products through the ISO certification
Application
DL-5, XTLZ-type multi-disc vacuum filter used in geological, metallurgical, coal, building materials, mines, schools, scientific research and experiments to carry out mineral optional units in the experimental work, as a flotation, re-election, magnetic and other operations After dehydration, test sample, solid-liquid separation. Machine mainly by the vacuum pump, Manifold air filter device, vacuum tank, and two filter disk group or its drainage through controlled automatic drainage, to achieve the purpose of solid-liquid separation. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
The device is a kind of filter can be intermittent or continuous laboratory-type filtration equipment can be used as product dehydration, the use of solid-liquid separation, simple structure, operation, convenient maintenance, filtering effects of high adaptability, for difficult to filter and concentration of minerals lower pulp filtration, the effect is most remarkable.
Technical specification
Model | Unite | DL-5C 240/120 | XTLZ 260/200 |
Disc diameter | mm | 240/120 | 260/200 |
Vaccum pressure | KPA | 91.2 | 80 |
1:(4-7) | 1:(4-7) | ||
Feed size | mm | 0.5 | 0.5 |
Dry material capacity | g | 500 | 600 |
Filter time | min | 1-10 | 1-10 |
Output water time | s | 30 | 30 |
Cake moisture | % | 20 | 20 |
Voltage | v | 380 | 380 |
power | kw | 1.6 | 1.5 |
Overall dimensions | mm | 1030/420/970 | 6500/5400/1140 |
