Feeder Machine/ Feeders/ Materials Feeder
- 250 Set / Sets per Month
- Shanghai
- T/T
- Hanging Vibrating Feeder Screw ZSW Series Vibration Feeder For Quarry Stone
- Coal Mining Industry Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
- Vibratory Feeder Industrial And Vibratory Feeder Controller Price
- Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
- Mining Selecting Vibratory Feeder Industrial For Sale
- Vibratory Feeder Industrial And Vibratory Feeder Controller Price
Product Details
Condition: | New | Application: | mineral processing, coal, chemical industry and other sectors | Power Type: | Electric |
Capacity(t/h): | 12 t/h | Place of Origin: | Jiangxi, China | Brand Name: | oasis |
Model Number: | 400/400 | Power(W): | 1100 | Dimension(L*W*H): | 1070/550/560 |
Weight: | 250 kg | Certification: | ISO9001:2008 | Warranty: | One year |
After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
1. Smoothly vibrating, long service life.2. Adjustable vibrating force and flow of materials.3. Low noise and power consumption.Trough to the mining machine and the Pendulum feeder for mineral processing, coal, chemical industry and other sectors will be granular and massive materials sent out from the storage silos by a variety of different types of feed devices, but not suitable for conveying ore powder and other powder materials.
This machine can be used as ball mill and the mine belt conveyor continuous and uniform supply of granular material feed set
Model Slot type | Unit | 400/300 | 600/500 | 980/1240 | 1000/1900 | 1060/2900 |
Feed size | mm | 50 | 205 | 300 | 300 | 350 |
Frequency bottom back and forth | r/min | 18.5 | 18.9 | 24 | 27 | 30 |
Crank Stroke | mm | 0-50 | 0-50 | 0-50 | 0-125 | 0-125 |
Capacity | t/h | 0-5 | 10-50 | 36-90 | 200-300 | 400-900 |
Power | kw | 3 | 4 | 7.5 | 11 | 25-40 |
Overall dimensions | mm | 2820/800/600 | 2700/900/850 | 3560/1000/1000 | 3900/1590/1350 | 4580/2950/1750 |
Weight | kg | 790 | 1050 | 1700 | 2690 | 3200 |
Model pendulum | Unit | 300/300 | 400/400 | 600/600 |
Feed size | mm | 20 | 35 | 50 |
Oscillation Frequency | r/min | 68 | 47 | 45.5 |
Eccentric travel | mm | 0-90 | 0-170 | 0-206 |
Capacity | t/h | 8 | 12 | 25 |
Power | kw | 1.1 | 1.1 | 1.5 |
Overall dimensions | mm | 1130/920/850 | 1070/550/560 | 1320/820/740 |
Weight | kg | 210 | 250 | 5500 |
