Laboratory Feeder
1.steady feeding rate
2.lagre conveying capacity
3.good warranty time
4.Mild Steel and Stainless...
Trough to the mining machine and the Pendulum feeder for mineral processing, coal, chemical industry and other sectors will be granular and massive materials sent out from the storage silos by a variety of different types of feed devices, but not suitable for conveying ore powder and other powder materials.
This machine can be used as ball mill and the mine belt conveyor continuous and uniform supply of granular material feed set
Model |
Unit | 400/300 trough | 600/500 trough | 980/1240 trough | 1000/1900trough | 1060/2900 trough |
Feed size | mm | 50 | 205 | 300 | 300 | 350 |
Frequency bottom back and fort | r/min | 18.5 | 18.9 | 24 | 27 | 30 |
Crank Stroke | mm | 0-50 | 0-50 | 0-50 | 0-125 | 0-125 |
Capacity | t/h | 0-5 | 10-50 | 36-90 | 200-300 | 400-900 |
Power | kw | 3 | 4 | 7.5 | 11 | 25-40 |
Overall dimensions | mm | 2820/800/600 | 2700/900/850 | 3560/1000/1000 | 3900/1590/1350 | 4580/2950/1750 |
Weight | kg | 790 | 1050 | 1700 | 2690 | 3200 |
Model |
Unit | 300/300 | 400/400 | 600/600 |
Feed size | mm | 20 | 35 | 50 |
Oscillation Frequency | r/min | 68 | 47 | 45.5 |
Eccentric travel | mm | 0-90 | 0-170 | 0-206 |
Capacity | t/h | 8 | 12 | 25 |
Power | kw | 1.1 | 1.1 | 1.5 |
Overall dimensions | mm | 1130/920/850 | 1070/550/560 | 1320/820/740 |
Weight | kg | 210 | 250 | 5500 |
