Help CenterISO Certification Agitation Tank/no Pollution Agitation Vat/Agitating Vessel/Washing Trommel With ISO
Related Products
-
Double Roller Electrical Sorter Machine ,titanium Ore MachineUS$ 8,000 - 9,000MOQ: 1 Set -
Zirconium Separator Machine, Rutile Ore Machine, Electrical Sorter MachineUS$ 7,500 - 8,600MOQ: 1 Set
-
Monazite Mining Machine, Iron Mineral Equipment, Electric SeparatorUS$ 7,500 - 8,600MOQ: 1 Set
-
Niobium Machine, Tin Ore Machine, Electric SeparatorUS$ 8,100 - 8,800MOQ: 1 Set
-
High Voltage Electric Separator Machine,zirconium Snad Separator MachineUS$ 8,100 - 8,800MOQ: 1 Set
Specifications
1.strong agitating capacity2, ensure higher indication3, more energy saved4, reliable operation and durableThe device is suitable for flotation, re-election, magnetic separation, etc. right concentration of not more than 35% and solid components of the slurry particle size of less than 1 mm to stir, but also can be used for flotation agents and other non-metallic minerals, mixing, so that mine suspended particles and in full access to the Pharmacy, mixing, in order to create conditions for sorting operations.
This series of stirred tank are the following: Agitating tank ,Lifting agitating tank,High concentration agitation tank, High efficiency agitation tank,Specifications of shemical agitation tank
Model |
U nit | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Diameter tank | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Height | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Volume tank | m3
| 0.124 | 0.25 | 0.58 | 1.15 | 2.2 | 4.4 | 11.2 | 19.1 | 46 |
Impeller Diameter | mm | 150 | 240 | 240 | 310 | 400 | 550 | 630 | 700 | 1000 |
Impeller speed | r/min
| 1000 | 530 | 530 | 492 | 320 | 230 | 230 | 210 | 121.6 |
Power | kw | 1.1 | 1.5 | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 | 30 |
Weight | kg | 260 | 320 | 480 | 908 | 1280 | 1760 | 2700 | 1805 | 8020 |
