Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CK64160 CNC Facing Lathe Machine

CK64160 CNC Facing Lathe Machine

Name: CK64160 CNC Facing Lathe Machine
Brand: MACH
SKU: 141436152
Availability: InStock

CK64160 CNC Facing Lathe Machine thumbnail-1

CK64160 CNC Facing Lathe Machine photo-1

US$ 117,280 - 120,080 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Dalian Mach Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 1600mm

Place of Origin Liaoning, China

Brand Name MACH

Model Number CK64160

Power(W) 22KW

Dimension(L*W*H) 3500 X 2600 X 2100mm

Weight 11000KGS

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

CK64160 CNC Facing Lathe Machine

Specification

ITEMS	CK64160
Max. swing over bed	Φ1600 mm
Max. swing over carriage	Φ1000 mm
Width of bed	1100 mm
Spindle nose	A2-15
Spindle bore	Φ130mm
Cone hole diameter and taper of spindle hole	Metric Φ140 1:20
Steps of spindle speed(Manual)	24
Range of spindle spec	2.5~250 r/min
Rapid feed for Z axis	6m/min
Rapid feed for X axis	12 m/min
Max. travel of Axis Z	500mm
Max. travel of Axis X	900 mm
Manual Vertical djustable stroke	500mm
Max. Input	0.001 mm
Tool post stations	4
Distance from the Main Shaft Center to the Cutter Installation Surface	50 mm
X/Z motor torque	33/21Nm
Power of main motor	22KW
Power ov cooling pump	250W
Overall dimensions(L×W×H)	3500×2600×2100mm
Net weight	11000 kg

Standard Parts

4-jaw chuck

Center

Lighting unit

Cooling unit

Auchor Bolt Foundation Block and Bolt

Special tools

Optinal Parts

H12 Turret

V4 Turret

Steady rest

Safe -guard device

Chip Conveyor

10 ton Spindle & Tailstock

Motor Drived Tailstock

Milling & Grinding device

Hydraulic antomatic chuck

Boring device

Guarantee & After-selling Service

We will supply enough spare parts and accessories with our machine when shipment. Within one year after receiving our machine, If there are any damaged parts or accessoreis, We will supply them to you by air-mail FREE OF CHARGE.

We will provide GOOD After-selling Service for our clients after shipment. It's basis of est


Certificate

CE Certificate & ISO Certificate

About our Company

Our factory is one of biggest professional manufactuer of producing heavy duty lathe in China. Our metal lathe are exported to many countries. Such as: USA, Canada, Portugal, Brazil, Chile, South Africa, Egypt, Ghana, Indonesia, Malaysia

...
