Automatic Box-Drawing Face Tissue Machine

Automatic Box-Drawing Face Tissue Machine

Features:

1. Under european CE standard designing, passed CE certificate, with CE or UL certificate for electric parts and with safety device, such as, safety-guard door, emergency stop, etc.
2. Most of parts are precisely processed by numerical-control machine; the key mechanical parts are under cnc processing; while the main outsourcing parts are world famous brand.

3. This machine adopts folding pattern through vacuum absorption together with manipulator, which possesses auto stop when paper breaks, auto electronic counting and pneumatic staggering function, thus facilitate to separate the designated quantity of tissue for next step if packaging.
4. Jumbo roll web-trimming function: on jumbo roll stand. electric sensor is mounted to detect and trace the jumbo roll for web guiding, materializing the mutual homologous.

5. Side-rolling embossment - independent pneumatic compress wheel, high rigidity embossment down roller. to produce non-embossment tissue, side-rolling embossment can protect tissue against separating and ensure to produce much more perfect tissue.

6. Horizontal jumbo roll stand -pneumatic jumbo roll feeding on wide belt; each roll is controlled by tension adjusting unit and pneumatic lifting device.
7. Optional items - advanced plc program control, frequency speed-regulator, electromagnetic speed-regulator, color printing or laminating unit.

Main Specification:

Model: CHMJ-200/2
1. Speed:                      1200-1600 sheets/min

2. Size of Jumbo Roll:    Width x Diameter: 420 x 1200 mm;  Size: 12-18 g/m2 (2 Ply)

3. Open size of final face tissue:   200mm (L) x 210mm ;

    Folded size of final face tissue: 100mm (L) x 210mm

4. Power:                      8.5kw(380v 50Hz);

5. Gas:                          0.5-0.8MPa, 0.30M3/min.
6. Overall size of machine:    4.l×1.7×2.1 Meter
7. Weight:                     2.5 tons











About our company:



Our company specialize in exporting face tissue machine, napkin tissue making machine, wet tissue machine, paper cup machine,etc for more than 20 years and export them to many countries. Such as: South Africa, Ghana, Kenya, Nigeria, Indonesia, Vietnam, UAE, Saudi Arabia,etc.

....
