XW5032C Universal Knee-Type Milling Machine
Features
1.Rectangular table guideways with high stability
2.Hardened and ground table surface, guideways
3.Automatic feeds on X,Y axes, motorized lifting andlowering of table on Zaxis
4.Headstock swivels +/-35'
Technical Data
SPECIFICATION | UNIT | XW5032A | XW5032B | XW5032C |
TABLE SIZE | MM | 1320×320 | 1320×320 | 1320×320 |
SPINDLE TAPER |
| ISO50 | ISO50 | ISO50 |
SPINDLE SPEED RANGE | R/MIN | 58-1710 | 58-1710 | 58-1710 |
TABLE TRAVEL | MM | 800(750)×300 | 800(750)×300 | 1000×300(MANUAL) |
NO./WID./DIS. OF T-SLOT |
| 5-14-63 | 5-14-63 | 5-14-63 |
DISTANCE FROM SPINDLE NOSE TO TABLE SURFACE | MM | 45-445 | 35-435 | 35-435 |
DISTANCE FROM SPINDLE AXIS TO VERTICAL GUIDEWAY | MM | 320 | 360 | 360 |
SPINDLE MOTOR POWER | KW | 4 | 4 | 4 |
OVERALL DIMENSION(L×W×H) | MM | 1770×1820×1880 | 1770×1820×1880 | 2020×1820×1880 |
NET WEIGHT | KG | 2300 | 2300 | 2300 |
Characteristic:
1. Rectangular table guideways with high stability
2. Hardened and ground table surface, guideways.
3. Automatic feeds on X,Y axes, motorized lifting and lowering of table on Z axis.
4. Headstock swivels +/-35°
About our company:
We are one of biggest manufacturer of producing CNC Milling Machine, Vertical machining Center, Universal Milling Machine, CNC Lathe,etc in China. We entered the top 8 machine tool builders in the world. Our CNC Milling Machine sell to more than 100 countries and regions worldwide.
...
