Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale

Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-1
Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-2
Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-3
Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-4
Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-5
Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale photo-6
US$ 9,500 - 14,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangxi, China
Brand Name:
MACH
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangxi, China
Brand Name MACH
Model Number CY01
Voltage 380V
Power(W) 25KW
Dimension(L*W*H) 3500x1200x1850mm
Weight 1850kgs
Certification CE
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas

Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





Product Description



Brief Introduction:

Automatic Colorful High Speed Straight Straw Making Machine is a tubing extrusion line.

It is composed of extruder and die,Vacuum calibration and cooling unit, hauloff and rotary cutter or coiler, all the machine's controls base with the control elements ergonomically adapted to permit easy operation. The system is also suitable for extruding straws, refiltubes and most small diameter tubing and a wide range of industrial applications.





Main Specification:
Typical Capacity:

Drinking Straws                30,000 -- 40,000pcs/h
Cotton swab sticks           60,000pcs/h
Pen Refills                         40,000pcs/h

Min. Diameter:                 3.0mm

Max.Diameter:                 12.00mm

Min. Length:                      90mm

Max.Length:                      300mm

Total Power:                     25 KW

Working Power:               10 KW
Material:                            PP
Ends:                                 90°/90°, 90°/45°, 90°/60°, 45°/45°, 60°/60°
Colors:                              Single,Two or Three, SPIRAL STRIPES,STRAIGHT STRIPES.
Operator:                          One operator is sufficent to run the line

Area Requirement:          Length: around 8 meter.    Width: around 2 meter.



Raw Material:                 Polypropylene (P.P )

Grade:                             Extrusion & Drawing

Shape:                             Pellet

Melt Index:                       2.5

Drawing Intensity:           380/ 350

Kneading Modulus:       17000

Rockwell Hardness:      100

Vica Soften Temperature: 160 C

Rotary Cutter:
Fitted with either single or double rotary cutter, suitable for light duty applications driven by variable speed gearbox. Inclides cutting and quick bushes with necessary guarding. Inverter control
Hall-off and Rotary Cutter:
Hall-off be combined with Rotary cutter.



Pictures:



 Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





We can supply High Speed Automatic Drinking Straw Extrusion Machine  in one color, two colors, three colors.



Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





Packaging & Shipping



Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale



Best Price Automatic Colorful High Speed Straight Straw Making Machine For Sale





Our Services



Quality is our forte and we have clients spreading all over the world. We are committed to a well-defined and self-framed quality policy. The policy revolves around through and repeated checking of the products. We are the regular exporters of our products throughout Asia, Africa and several European countries. Our after-sales service terms and conditions as follows.

  • The machines are tested and have trial production in our factory before leaving our factory and they are shipped out only after the customers are satisfied with them.
  • When the machines are tested, our technicians will train the customers’ technicians in theory and practice till they grasp the skills.
  • During this period of one year warranty , if the machines were damaged by non-artificial reasons, we are responsible for repairing or changing parts.
  • During this period of warranty, if there is something wrong with the machine, we are responsible to provide project for solving this problem at the soonest, and help customers to restore production as soon as possible.
  • After the warranty, we charge only cost price for maintaining the machines within three years.
  • Other after-sale terms can be agreed by buyer and seller in addition.
Company Information

Dalian Mach Co., Ltd. have a group of professional engineers in charge of technology, manufacturing, installing and testing, so we can guarantee that our plastic drinking straw machine will put on good performance based on high quality.

Our Three Color High Speed Automatic Drinking Straw Extrusion Machine have been exported to more than 60 countries such as Canada, the U.S.A., Italy, France, Guatemala, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, the U.A.E., Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya and Ghana.

We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service





FAQ



Q:Why choose our straw making machine?

A: 1 . High quality with competitive price
     2 . 25 years export experience
     3 . CE,ISO Certificates
     4 . 24 HOURS ONLINE SERVICE (MSN,SKYPE, Trademanager)
     6 . 12 months quality warranty
     7 . Oversea engineers available for problem resolving

Q:Can we start with small quantity ?What's the MOQ?
A:  We can accept orders with any quantity. The MOQ is 1 unit.

Q: Do you have QC or any safety standards for your straw making machine?
A:  yes,we have established a highly strict quality control department to guanrantee good quality.

Q: How can we learn to operate the straw making machine?
A: Operation teaching video and instructions even engineer are available.





...
