Long Burning Smokeless hexagon briquette charcoal machine
Brief introduction of hexagon briquette machine:
The height of the final charcoal briquettes can be 7-12cm, long burning time, no smell, high
density. this type charcoal grill machine with hydraulic pressure, the pressure can reach 160ton, can be controled by computer. The capacity reach 2 ton per hour. change mold can do the shisha.
The final products of hexagon briquette charcoal machine:
The whole production line related to hexagon briquette charcoal machine:
Raw materials----carbonization furnace----charcoal crusher----binder mixer----wheel mill----
shisha charcoal machine----finished bbq charcoal----dryer
If want to make bbq charcoal, must need to make attention on following:
1. Raw material: hardwood charcoal, coconut shell charcoal, bamboo charcoal are good material for make shisha briquettes.
2. Only good quality shisha charcoal tablet press machine can make good shisha hookah briquettes,our machine are patented products,
we have hydraulic type and mechanical press type for you choose.
3. It need to confirm the binder furmola is natural, smelless, nontoxic.we can provide the special binder foumula after order for free.
4. Also we can depend on your specific situation design the production line to you.
Technical parameters of hexagon briquette charcoal machine:
Model |
LTYJ-9 |
LTYJ-48 |
Applicable materials |
Charcoal powder, coal powder, sawdust, any powder material |
|
Capacity |
11-16 pieces/time 20-40 times/min |
48 pieces per time(30mm) 8-20 times/min |
Motor |
7.5 kw ( 4 pole) |
18.5 kw (4 pole_ |
Diameter of briquettes |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
Feeding materials |
≤3mm |
≤3mm |
Briquette shape |
Round shape and cubic shape or as customers’ request |
Round shape and cubic shape as customers’ request |
Pressure |
40-60tons (adjustable) |
40-150tons |
Pressure type |
Mechanical press |
Hydraulic press |
Overall size |
2500*950*1550mm (include conveyor) |
3500*2000*1800mm (include conveyor) |
Packing size |
1500*1200*1750mm |
2100*2100*1900mm |
Weight |
1500kg |
5500kg |
Pre-sale service:
1.According to the customer needs to recommend relative models machine.
2.According to the customer's special requirements to customize equipments.
3.Our engineers will supply the site and equipment drawing.
After-sale service:
1.According to the purchase contract,our company can send engineers to help installation.
2.The quality guarantee is 1 year,not including the wearing parts.
3.Collecting customer feedback,solve the real problems faced by customers.
4.Our company supply sapre parts the whole year.
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Our working experience about hexagon briquette charcoal machine
Lantian Mechanical Plant, which located in Gongyi, Henan province,is a modern enterprisewhich setsthe scientific research,
production and sales as a whole.We have a modern management system,the first-class processing art, perfect detection means, high quality science and technology talent team
and after-service system. Our company has been rated as "Quality Trustworthy Unit" "Brand-name
and High-quality products" and "QualityManagement Advanced Unit".In order to meet the different
requirements of customers, we designed and researched many types of charcoal processing
machine including charcoal & coal briquette machine, Shisha/hookah charcoal machine,sawdust
charcoal briquette machine, tablet press machine, rotary dryer vertical dryer, belt mesh dryer
and mixer, crusher, blinder, etc.
Other assistant equipments of the shisha charcoal machine:
1)crusher
the first step of shisha charcoal machine is to crush raw material into fine hookah powder. The smaller the hookah powder's size is, the better.(hookah charcoal pressing machine)
2) whell mixer
The second step of the shisha charcoal machine is to mix charcoal powder with natural binder evenly. The reason why we use wheel mixer is that wheel mixer can not only improve shisha powder's density, but also press shisha powder into smaller size. (hookah charcoal pressing machine)
3) Box dryer:
The last step of the shisha charcoal machine is to dry shisha briquettes in box dryer. Due to the liquid binder, shisha charcoal will have 15-20% water content, so we need to dry the briquettes to 3-5%( hookah charcoal pressing machine)
Welcome to our factory to check performance of the shisha charcoal machine or contact with me at any moment.
