2015 Hot sale cube/round shape coconut shell charcoal briquette machine
Brief introduction of cube shape coconut shell charcoal briquette machine
The coconut shell charcoal cube machine can press many different kinds of chips/tablets (circle, square, irregular, etc) by replacement of some spare parts. We produce the shisha hookah charcoal machine.The machine can press dry powder into circle chips/tablets, square, rectangle, ring, taper and so on by changing moulds. The finished products’ surface is smooth and its pressure as well as density can be adjusted.
Shi sha sample:
For the round shape: the size is usual diameter 28-35mm; for the cube shape the size is usual 20*20*20mm, 25*25*10mm, 20*20*10mm, most popular is 25*25*10mm, many clients choose this size.
Main features of cube shape coconut shell charcoal briquette machine:
1)Special design is suitable for light powder materials.
2)Reasonable structure with easy clearance and maintenance.
3)Transmission system in main gear box below airtight is completely separated, reducing noise and wear.
4)The model of this shisha charcoal briquette machine is changeable.
Pictures about the main parts of coconut shell charcoal briquette machine
The whole production line related to coconut shell charcoal briquette machine:
Technical parameters of cube shape coconut shell charcoal briquette machine
| Model | LTYJ-9 | LTYJ-48 |
| Applicable materials | charcoal powders, coal powders, sawdust, any powders materials | |
| Capacity |
11-16pieces/time 20-40times/min |
48pieeces per time(30mm) 8-20times/min |
| Motor | 7.5kw(4 pole) | 18.5kw(4 pole) |
| Diameter of briquettes |
20, 25,30,33,35,38,40,43mm(round): 20-40mm(cubic) |
20,25,30,33,35,35,40,43mm(round)20-40mm(cubic) |
| Feeding materials | <3 mm | <3 mm |
| Briquette shap | Round shap and Cuib shap or as customers′ request | Round shap and Cuib shap or as customers′ request |
| Pressure | 40-60tons(adjustable) | 40-150tons |
| pressure type | Mechanical press | Hydraulic Press |
| Overall size |
2500*950*1550mm (includes conveyor) |
3500*2000*1800mm (includes conveyor) |
| Packing size | 1500*1200*1750mm | 2100*2100*1900mm |
| Weight | 15000kg | 5500kg |
Our promise about cube shape coconut shell charcoal briquette machine
Pre-sale service:
1.According to the customer needs to recommend relative models machine.
2.According to the customer's special requirements to customize equipments.
3.Our engineers will supply the site and equipment drawing.
After-sale service:
1.According to the purchase contract,our company can send engineers to help installation.
2.The quality guarantee is 1 year,not including the wearing parts.
3.Collecting customer feedback,solve the real problems faced by customers.
4.Our company supply sapre parts the whole year.
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Our working experience about cube shape coconut shell charcoal briquette machine
Lantian Mechanical Plant, which located in Gongyi, Henan province,we are specialized in the coconut shell charcoal briquette machine since 1993. It is almost 30 years. We have sold our machine to almost 40 different countries.
Other assistant equipments of cube shape coconut shell charcoal briquette machine
1) Charcoal crusher(grinder):
the first step of coconut shell charcoal cube machine is to crush raw material into fine charcoal powder. The smaller the charcoal powder's size is, the better.( less than 3mm)
2) Mixer:
The second step of coconut shell charcoal cube machine is to mix charcoal powder with natural binder evenly. The reason why we use wheel mixer is that wheel mixer can not only improve charcoal powder's density, but also press charcoal powder into smaller size.( coconut shell charcoal cube machine)
4) Box dryer:
The last step of coconut shell charcoal cube machine is to dry charcoal briquettes in box dryer. Due to the liquid binder, the final charcoal briquettes will have 15-20% water content, so we need to dry the material.
Welcome to our factory to check performance of the shisha charcoal machine or contact with me at any moment.
