Hot selling Automatic fly ash brick making machine Road brick machine from Lantian made in China
| Technical parameters | |||
| Specifications Model | Production (pcs/h) | Motor Power (kw) | Dimension (mm) |
| LTM 90-4.0 | 20,000-28,000 | 132+315 | 9225x2890x3590 |
| LTM 75-4.0 | 16,000-24,000 | 110+250 | 8955x3075x3310 |
| LTM 60-4.0 | 15,000-22,000 | 90+200 | 8655x2450x2820 |
| LTM 55-4.0 | 14,000-20,000 | 75+180 | 8360x2800x3590 |
| LTM 50-3.5 | 13,000-18,000 | 55+132 | 5350x1800x2100 |
| LTM 45-3.0 | 10,000-13,000 |
110-132 | 4960x1680x1750 |
| LTM 40-3.0 | 8,000-10,000 | 90-110 | 4750x1500x1650 |
| LTM 35-2.0 | 6,000-8,000 | 55-75 | 3750x1340x1550 |
| LTM 30-2.0 | 4,000-6,000 | 45-55 | 3450x1220x1320 |
Our features and advantages:
1. Rain erosion resistant.
2. Non-slip, Wear resistance.
3. No pollution , Ecological environmental protection.
4. Good at high temperature and cold temperature.
5. Various colors and sizes.
6. Convenient construction, Easy operation and easy to repair and maintain.
The working principle of Brick Machine:
(1) Put prepared material into the hopper and distributor will feed material into the molds under the hopper, then the pressure device will press the powder.
(2) Powder will be formed to a certain shape under the stronger press.
(3) Next, the briquette will be pressed out off the mold by auxiliary punch, and fall on the belt conveyor.
(4) With the rotating of dieplate, this process will be continuous.
Production Line Equipments of Cement Brick Block Making Machine:
Beside the Clay Brick Making Machine, our factory can also provide the auxiliary
equipments for the whole production process. Includes: box-feeder, crusher,
double-shaft mixer, roller screen, cutter, and some other devices. The following
are the main production equipments:
1. LTM series box-type feeder is the feeding equipment which is uesd to balance and
ration during brick production. It is applicable to various bulk and block materials with
controllable feeding speed and adjustable feeding quantity. (Interlocking Brick making
machine)
2. Futher crush clay and other raw materials by the roller fine crusher, until the raw
material size is ≤ 2 mm. Both ends of the fine crusher are equipped with regulating
pinched security block which are used to protect rolling circle and equipment. (Inter
locking brick making machine)
3. Conveying the fine clay powder into double-shaft mixer by belt conveyor, mixing
and blending with water to futher enchance the comprehensive plastic index of raw
materials. It is mainly used for watering and mixing treatment for clay, shale, coal
gangue, coal ash, and other raw materials. (Interlocking brick making machine)
4. After extruding, the wet long striped brick are cut into different size of pieces green
bricks by the automatic slitting cutter. (Interlocking brick making machine)
1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.2). pofessional responding team: would be very fastly and exactly to send you offer.
3). choose suitable machines and make producing plan according to the raw materials, final shapes and output capacity.
4). offer reasonbal price to meet your budget.
5). invite customers to our factory, demostrate the machines, let you know how the machine work, and compare the quality with other suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fastly delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.
4). supply spare and wearing parts of our machines.
5). any feedback of our Charcoal or Coal Brick Machine can be told us, and we will try our best to support you.
6). technology knowlogy shares with you.
7). help for any other machine that we haven't.
1. After visiting our factory and our customers factory, we can talk about the details of the deal, choose types of clay brick making machine south africa according to your requirement on capacity.
2. When customers coming, we can provide working site of brick making machine to see how the machines working and how is the process.
3. After you order our machines, our factory can provide professional technician go abroad and help to install the brick making machine, teach your worker to operate the machine, impart the skills of brick making, make sure you can produce perfect bricks.
Our factory is specialized in the field of full set machinery of automatic brick making
machine. After 30 years' development, our factory has a contingent of top-north
researcher, an advanced manufacturing technology, perfect detection means, and
a complete quality assurance system. According to the inferior soil, coal gangue,
shale, fly ash and other waste reside, the technicists design energy-efficient vacuum
extruder, automatic strip and brick cutter, full auto setting machine, double stage
crusher, electric excavator, green brick delivery trolley, unloading trolley, etc.
