Multi-function suitable for briquette wheel mixer
- 66 Set / Sets per Month
- Qingdao Shanghai Lianyungang etc
- T/T L/C D/P D/A Credit Card PayPal
- Continuous carbonization machine for charcoal making
- Cheap Charcoal Briquette Machine(86-15978436639)
- Wholesale Price Charcoal Briquette Machine(86-15978436639)
- Ball Charcoal Briquette Machine(86-15978436639)
- Charcoal Briquette Making Plant(86-15978436639)
- Small Scale Charcoal Briquette Machine(0086-15978436639)
Product Details
Place of Origin: | Henan, China | Brand Name: | Lantian | ||
Model Number: | lt | Voltage: | 380V, 380v | Power(W): | 15kw |
Weight: | 800kg | Dimension(L*W*H): | depend on the types | Certification: | CE ISO |
Warranty: | One Year, 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Multi-function suitable for briquette wheel mixer
Suitable for the mixing of powder and granular material, such as charcoal ,coal ,cement, clay, resistance
of fly ash, slag, tailings, sand etc.widely used in charcoal/coal briquette machine ,The no-burned brick,
steam pressure brick, refractories, ceramics, building materials and other industries.
Advantages of wheel mixer:
1.High production efficiency:Using wheel rolling, the raw material has repeatedly rolling and mixing, making
the raw material mixed more fully, improving the bond degree of raw material.
2.Low cost:Low power, high output, low power consumption, high cost performance.
3.Automatic setting:Using gas control switch,can be directly control by computer.without specialized manual
operation.
4.Simple operation:Not need professional technology.
Working principle of wheel mixer:
Wheel mixer is mainly composed of the grinding wheel,grinding disk,mixing room,scraper, transmission device,
deceleration device, discharging device,frame and so on.The height of wheel can be automatically adjusted,
When have a large or hard material, the rolling wheel can automatically rise,over the hard material, due to its
own gravity and automatically fall.The grinding wheel and rotating shaft is connected through the crank .Motor
drive speed reducer, driven by the roller, scraper, transmission device composed of rolling device rotation.In
the process of rotation, rely on the weight of the wheel the material is mixed,At the same time, the rotation of the
wheel is affected by the friction force.After the material is stirred evenly, open the discharging device, Material
is discharged from the scraper to the discharge port.
Technical parameters of wheel mixer:
Raw materials/time | 0.5(m³) |
Mixing time | (3-8)min/time |
Width of wheel | 240(mm) |
Diameter of wheel | 620(mm) |
Spindle speed | 26r/min |
Power | 11Kw |
Size of machine | 1800×100(mm) |
Weight | 1900kg |
Our service :
1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.
2). professional responding team: would be very fast and exactly to send you offer.
3). choose suitable machines and make producing plan according to the raw materials, final shapes and output capacity.
4). offer reasonable price to meet your budget.
5). invite customers to our factory, let you know how the machine work, and compare the quality with other suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fast delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.
We are a 30 years factory located in "mechanical city" Gongyi city, Henan province, China. 30 dedicated development, we have become to a factory including design, manufacture, sale and after-sales service. Good product quality and finest after-sales service are our intention and goal.
Our main products are different kinds briquette machines, coal briquette machine, charcoal briquette machine, shisha charcoal briquette machine, biomass briquette machine, and other auxiliary machine crusher, dryer, feeder, conveyor machine, mixer, etc.
