Lantian rotary kiln furnace for activated carbon
Main technical parameters:
| SERIAL | ITEMS | ROTARY KILN |
1 | Principle | Physical Steaming Aerobic Activation |
| 2 | Main material | 1.Manganess steel 2.Fire bricks&Insalate bricks 3.Waste gas steam boiler system 4.Gears &Roller 5.motors |
| 3 | Raw material | 1.hard wood charcoal(wood charcoal, coconut shell charcoal,palm shell charcoal,Kmili charcoal,etc) or charcoal mix with few raw shell mixed material, 2.natrual size or granular mesh size |
| 4 | Size: | (18-24)*(1.5-2.5)(dia)m ,one out put hole .not contain the boiler and feeding system |
| 5 | Procedure for AC | 1.After feeding ,material will convey slowly to the output part accroding to the Kiln turn around 2.blower will take the air into the Kiln at the feeding part to increase the temperature,at the same time steam injection into the Kiln for activation 3. Waste gas boiler get heating from the Kiln ,creat steam then react back to Kiln, 4.Output by circly in same step with the turnning of the Rotary Kiln 5.Draft fan and smoke pipe will take out the waste air and extra heating in the Kiln |
| 6 | Temperature control | 850-1100 degreee |
| 7 | AC quality | 1.can reach Iodine value 1500 2.hardness 80-95 3.can use as carrier AC FOR HIGH QUALITY AC |
| 8 | AC application | A: water purification B: Air clean C:MSG D:Alcohol E:Medicine F: Chromed plated G:Petrochemical industry H:Filter I:Carrier actived carbon |
| 9 | Capacity | 3-5tons per day based on:1000mg/g raw material :coconut charcoal or other hard shell charcoal Iodine value: 1000mg/g |
| 10 | Project time | 1 month preparation 2month installation,1month trainning,totally 4month |
| 11 | Start fire | first time 2days,normal 1day |
| 12 | Electricity consumption | 500-800KWH per day |
| 13 | Shipping | 4*20GP,4*40 OT ,1or 2 SPECIAL PLATFORM OR BULK SHIPPING |
| World Project Show click pictures for details |
This carbonization furnace is fueled by the syngas(carbon monoxide, methane, ethane etc.)
from the furnace itself.The biomass raw material will produce plenty of combustible gas during the pyrolysis of the carbonzation process,the syngas will became pure combustible gas after wood tar, wood vinegar other impurities was isolated by the filter and purification system (gas cleaner / dust-removal / purify tank / scrubber)
The gasifier is used to preheating the carbonizer,when the temperature reach to 300℃,the feeding screw conveyor start to feeding raw material into the carbonizer.the material will produce fuel gas,which will be collected and used to heating the carbonizer after cleaning by the filter and purification system. The temperature of carbonizer will control at 600 degrees Celsius.
When the carbonizer can produce enough flue gas and reach to self sufficient combustion, close the gasifier and open all the flue gas valve of the carbonizer gradually, finally achieve flammable gas self-sufficiency carbonization.
Process description of sugarcane bagasse carbonization furnace:
♦ Pre-sale service: design and manufacture wood pellet machine for you as your special requirements, provide you with project, process design, and purchase program.
♦ On-sale service: accompany with you to look around our factory, explain the manufacture process of our machines, and check the working performance of our machines.
♦ After-sale service: engineers are available to install and debugging equipment of the whole production line, besides, commissioning and training operators on site.
1. Established in 1980s, our company covers an area of 100,000 square meters which includes 66,000 square meters of workshops. We have the most advanced technology, most strict process, from material purchase to the finished products, all strictly according to the national quality inspections standards.It mainly specilize in charcoal making machine, sawdust briquette machine,briquette machine,powder making machine,extruder machine, BBQ machine,honeycomb briquette machine,carbonization furnace,heat pump dryer and so on.
2. As manufactures, we have more than 30 years of experience, our products all achieved patent certificates, and our company has many times achieved the title of honer: " Observe Contract and Keep Promise" " Quality Trustworthy Product" "Good After-sales Service Reputation", etc.
