China Generator 300KW Generadores Electricos

Name: China Generator 300KW Generadores Electricos
Brand: PUYANG
SKU: 141415332
Availability: InStock

US$ 5,000 - 240,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

PUYANG

Model Number:

PFC375

Dalian Puyang International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name PUYANG

Model Number PFC375

Output Type AC Three Phase

Speed 1500RPM

Frequency 50Hz

Rated Power 300kw

Rated Voltage 400/230v

Rated Current N/A

China generator 300KW generadores electricos

Diesel generator features:
- Prime power: 300kw/375kva
- Standby power: 330kw/413kva
- Voltage: 230/400V (adjustable)
- Power factor: 0.8 (lagging)
- Connect type: three-phase and four-wire
- Insulation class: H/H
- Protection grade: IP21-23
- Consumption:71.8 l/h diesel at full load
- Dimension: 2960*1400*1700 mm
- Weight: 2920 kg
Diesel generator features:
- Voltage regulation: ≥ ±5%
- Voltage regulation, stead state: ≥ ±1%
- Sudden voltage warp (sudden reduce): ≤ +20%
- Sudden voltage warp (sudden increase): ≤-15%
- Voltage stable time (sudden reduce): ≤1.0s
- Voltage stable time (sudden increase): ≤ 1.0s
- Frequency regulation, stead state: ≤0.5%
- Frequency waving: ≤ 0.5%
- Frequency recovery time (sudden reduce): ≤ 1.0s
- Frequency recovery time (sudden increase): ≤ 1.0s
Engine features:
Engine brand: cummins
Engine type: in-line four-cycle and water cooled
Turbocharged and inter-cooler
Combustion type: direct injection
Model: NTAA855-G7
Maximum power:377 kw
Bore and stroke: 140*152 mmv
Coollant capacity: 75.0 L
Oil capacity: 37.0 L
Standard accessories of diesel generator set:
Standard control panel, exhaust silencer, flexible pipe, battery and battery cables, battery rack, operation manual and document

Our Advantages:

Solve your technical problems in 24 hours and provide international warranty service for engines
Design the appearance form according to customers’ request
Polyester varnish for appearance protecting for shining and raining
Two hours testing before out factory
ISO9001 and CE certification
OEM service offered by our company
