Doosan Series Diesel Engine Generator 60Hz
US$ 5,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
PUYANG
Model Number:
PFD
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
500kw Shangchai Diesel GensetUS$ 1 - 99,999MOQ: 1 Set -
200KW Shangchai Silent Diesel GeneratorUS$ 3,900 - 9,999MOQ: 1 Set
-
Low Prcie 200kw 250kva Generator Diesel China FactoryUS$ 1,999 - 19,999MOQ: 1 Set
-
Weichai Automatic 30kw Open Diesel Generator SetUS$ 1 - 99,999MOQ: 1 Set
-
50Hz AC Three Phase 250kva Diesel Generator Trailer TypeUS$ 10,000 - 280,000MOQ: 1 Set
Place of Origin
Liaoning, China
Brand Name
PUYANG
Model Number
PFD
Output Type
AC Three Phase
Speed
1800rpm
Frequency
60Hz
Rated Power
77kw to 540kw
Rated Voltage
400/230v
Rated Current
N/A
Doosan series diesel engine generator 60Hz
| PFD SERIES PARAMETER 60Hz | ||||||||
| No. | Genset Model | Output Power | Engine Model | Fuel Consumption(L/H) | Size(Open Type) | Weight | ||
| KVA | KW | Diesel | Lub. Oil | L*W*H mm | KG | |||
| 1 | PFD96-60 | 96 | 77 | D1146 | 18.50 | 0.085 | 2430*950*1400 | 1150 |
| 2 | PFD125-60 | 125 | 100 | D1146T | 24.10 | 0.108 | 2560*950*1450 | 1400 |
| 3 | PFD188-60 | 188 | 150 | P086TI-1 | 36.10 | 0.147 | 2700*950*1450 | 1450 |
| 4 | PFD225-60 | 225 | 180 | P086TI | 43.30 | 0.173 | 2700*950*1450 | 1500 |
| 5 | PFD313-60 | 313 | 250 | P126TI | 60.10 | 0.236 | 3120*1000*1500 | 1850 |
| 6 | PFD400-60 | 400 | 320 | P158LE-1 | 76.90 | 0.329 | 3020*1400*1800 | 2100 |
| 7 | PFD455-60 | 455 | 364 | P158LE | 87.50 | 0.350 | 3020*1400*1800 | 2150 |
| 8 | PFD556-60 | 556 | 445 | P180LE-S | 106.30 | 0.440 | 3270*1400*1800 | 2820 |
| 9 | PFD676-60 | 676 | 541 | P222LE | 130.10 | 0.560 | 3440*1400*1850 | 3350 |
Standard accessories of Doosan series diesel engine generator 60Hz:
- Standard control panel, exhaust silencer, flexible pipe, battery and battery cables, battery rack, operation manual and
- document
