We are specialized in manufacturing generator sets since 1999.
Features (alternator):
1)Alternators: Leroy-Somer,Stamford,Marathon,WT brushless (brand of ours)
2) Phase: 3-phase, 4-wires
3) Connection: Y type connection
4) Excitation: Self- Excitation
5) Voltage regulation: automatic
Technical Parameters
300KW Generator Model NTAA855-G7 | |||
Prime power: | 300kw/375kva | Standby Power: | 330kw/413kva |
Voltage: | 400/230V | Rated Speed: | 1500/1800rpm |
Frequency: | 50/60HZ | Rated Current: | 1800A |
Connection: | 3 phases 4 wires | Power Factor: | ≥0.8 |
Weight (Open Type): | 3150 KGS | Weight (Silent Type): | N/A |
Dimensions (Open type): | 3160*1140*1860MM | Dimensions (Silent Type): | N/A |
Diesel engine | Type | water-cooled, in line, 4-stroke, direct injection. |
Rated Power(KW) | 300kw | |
Intake Type | Turbocharged | |
No. of Cylinders | 6 | |
Cylinder Arrangement | V | |
Bore*Stroke | 140*152 | |
Compression Ratio | 13.5:1 | |
Mechanical Governor Rate | <5% | |
Electronic Governor Rate | <1% | |
Exhaust Temperature(°C) | <600 | |
Lube Oil Consumption(l/h) | 0.091 | |
Rate Fuel Consumption(l/h) | 86 | |
Alternator | brand | Leroy somer or Marathon |
Protection Grade | IP23 | |
Power Efficiency | 90.30% | |
Voltage Regulation | <±1 | |
Excitation Type | BRUSHLESS | |
Insulation Class | H |
Warrenty:
12 months or 1000 running hours from shipment date. If the quality problem arise during the warranty period, and verified the problem is caused by our genset-body instead of external or natural reasons. (Refer to all kinds of natural disaster, shipping, loading, unloading, wrong-operation, etc), we will supply the relevant spare parts free of charge for maintenance; after the warranty period, we can supply the required spare parts for you under cost prices.
