Low consumption 30TPD wheat flour milling machines with price for fine wheat flour
- 100 Set / Sets per Month
- Qing dao Shanhai Tianjin
- Credit Card
- Automatic Maize Flour Mill Wheat Corn Flour Milling Machine Maize Mill
- Automatic 20tpd Wheat Maize Corn Semolina Rice Roller Flour Griding Machine Wheat Flour Mill Milling Machine
- Wheat Rice Grain Grinder Flour Mill Milling Machine For Home Use
- Widely Used Wheat Rice Grain Grinder Flour Mill Milling Machine
- Small Scale Corn Grinder Mill Machine Grain Crusher Mill Making Machine
- High Quality Grinding Mill Machine for Maize Wheat Soybean
Product Details
Place of Origin: | Henan, China | Brand Name: | Chuanyue | Model Number: | Wheat flour milling |
Production Capacity: | 30T/24hours | Voltage: | 380v | Power(W): | 87.2kw |
Weight: | According to configuration | Dimension(L*W*H): | 16*7*7m | Certification: | CE ISO |
Warranty: | 1 year for free | After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
30TPD wheat flour milling machines
The flour milling plant fits for the production of tailored flour and all-purpose flour. The flour mill is with advanced technical process and flexiable adjustment. It can produce grade flour and special flour. The finished flour is usually used to produce bread, biscuit, spaghetti, instant noodle, etc
Type | Power(kw) | Line Dimensions(m) | Brief process |
MF-30 | 87.2 | 16*7*7 | Cleaning part: 2 siftings--2 scourings--1 destoning ---1 washing--2 magnetic separations;
Milling part: 3 hulling and 3 wheat core millings, separating wheat skin from wheat core to grind them partly.
|
MF-40 | 128.6 | 20*7*7.5 | Cleaning part: three sieves, two beating, two removing stone, One washing and three magnetic selecting
Milling part: eight milling, two six-bin square sifter, one purifier and two bran finishers making up "4B,7M, 1S, 2T" process .
|
MF-50 | 135.5 | 28*7*7.5 | Cleaning part: One screen, two scour, two destoner, one damper, and one magnetic separator.
Milling part: Four sets of double roller mill, three sets of Double-section high efficiency square sifter consist of the milling technology of four break, three reduction, one scratch ,one bran brusher |
MF-100 | 300 | 35*7*15.7 | Cleaning part: 4 break-5 reduction-1 scratch-1tail-2 purifying-1 inspection-2 bran brushing
Milling part: 3 sifting-2 scouring-2 destoning-3 magnetic separating-1 washing-2 dampening |
Characteristics of our production line:
1. Simple structure and low investment, offer different configuration according requirements
2.Professional craft,low noise and dust.
3. Our advanced enginner has 17 years design experience in domestic
4.The core machines are developed by ourself, have a patent
5. well reserved after service.
Wheat flour milling plant line preview
1.Triple cleaning sieve: Through the beat function of the wheat scourer, brusher to remove dust sand small seed, bacterial count and insect seed.
2.Damper: Dampening the wheat bran before mill to ensure the bran's integrity during the milling processing, avoid the bran going into the flour to keep flour quality.
3.Wheat scourer: clean the surface of the wheat, ensure that the play ash content of wheat finished points can reach to the standard.
4.Destoner: Mainly remove stone in the wheat to protect them milled into the flour and also protect the roller on the milling process.
5.Rotary sieve classifier: through value drive shaft makes the sifter planar rotating to separating the impurities from the grains.
6.Mill: Mill the wheat to break the integrity by the roller moving
7.Double-plan sifter: To separate the flour and bran, also separate large size and small size to enssure flour quality.
8.Wheat bran brushing machine: separate the fine particle from the surface of wheat bran. Thus reducing the rate of the bran, enhance the rate of the powder.
9.High pressure fan: offer wind force, wind pressure
1. Raw wheat storage(silo or warehouse)
2. Cleaning system(sifter, destoner, magnetic separation, scourer)
Clean up the middle and small impuritier from wheat, dust, stone, magnetic materials. Including beating, screening, destoning, magnetic separatation and dampening. This stage is to prepare wheat for being milled and to protect the machinery as well.
3. Milling system(roller mill, plansifter, purifier, impact detacher)
Mill: mill the wheat to break the integrity by the roller moving;
Sifter: separate flour from bran, also separate large, small size to enssure flour quality.
4. Flour packing and stacking
The packing part can be manual or auto operation, which can be designed according to
customer's requirement and machine capacity.
We offer the technology flow chart
Welcome friends come to china and visit our factory
Established friendship with our customers
Henan Chuanyue Machinery Co.,Ltd is one of china most professional and honest grain processing equipment company.Our senior engineer has 17 years work experience and 70%domestic grain processing line is designed by our technicians and we are sure of offering you fittest technology with the most competitive prices.
How to choose a flour mill?
Two of the features that affect prices are the material of the flour mill, the noise level and their adjustability. Generally, our turn-key project of flour mill is made of stainless steel, operate with low noise level, have lower heat production, generate less dust in the air.
We also offer the following grain production
Series of corn product line (flour)
Series of Dual corn product line (Grits, flour)
Series of Multi corn product line (flour,grits,germ)
Series of Dual corn product line (flour,germ)
Corn germ oil production line
Wheat flour milling production line
Whole wheat flour (with wheat bran) production line
Buckwheat processing line
Corn gluten flour production line
If you need more technical information and exactly price, please contact with us freely. Our professional technique team will give you the best service.
