1. Brief Introduction of electromagnetic vibrating feeder for benefication:
*.Widely used as crushing and screening joint equipment in the cement plant for continuously and evenly feeding cement materials
*.In the cement production line, the even and continuous feeding helps avoid the feeding hole blocking of cement crusher
2. Features of electromagnetic vibrating feeder for benefication:
*.Double screening and embodies the functions of dirt removing, screening and feeding
*.It is characterized by even feeding, excellent continuity and adjustable vibrating force
*.Smooth operation, great feeding capacity and high efficiency
*.Eccentric block is the vibration source which features smooth operation, low noise, little electricity consumption, excellent adjustability and causes no material clashing
3.Specification of electromagnetic vibrating feeder for benefication:
Type | GZD850 X3000 | GZD960 x3600 | GZD1100 x3800 | GZD1200 2400x | GZD1300 X4900 | GZD1500 X6000 |
Max.Feeding Size | 400 | 500-580 | 580 | 580 | 650 | 800 |
Handling Capacity (t/h) | 80-120 | ~150 | ~240 | ~280 | ~450 | ~600 |
Motor Power(kw) | 7.5 | 2.2 x2 | 3.7 x2 | 5.5 x2 | 7.5 x2 | 8.5 x2 |
Installation angle (0 ) | 5 | 5 | 5 | 5 | 5 | 5 |
Funnel Size (mm) | 850x3000 | 960x3600 | 1100x3800 | 1200x4200 | 1300x4900 | 1500x6000 |
Overall dimension (mm) | 3110x 1800 X1600 | 3850x1950 X1630 | 4400x2050 X1660 | 4500x2050 X1700 | 5200x2350 X1750 | 6280x2350 X2400 |
