GZ5V Mechanical Variable Gearbox Dry Mix Concrete Shotcrete Machine

GZ5V Mechanical Variable Gearbox Dry Mix Concrete Shotcrete Machine photo-1
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Max. Conveying Distance:
200m
Max Aggregate Size:
15mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai or Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Max. Conveying Distance 200m
Max Aggregate Size 15mm
Hose Inner Diameter 51 mm
Air Consumption 9m3/min
Place of Origin Henan, China
Brand Name GEC
Model Number GZ-5
Voltage 380v 220v
Power(W) 5.5kw
Dimension(L*W*H) 1.42*0.75*1.2m
Weight 750kg
Certification ISO CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

GZ5V mechanical variable gearbox dry mix concrete shotcrete machine



Product Description



GZ5V mechanical variable gearbox dry mix concrete shotcrete machine description:

GZ-5V Shotcrete machine is mainly used for dry-mix shotcrete and damp-mix shotcrete. It has some obvious advantages such as advanced technology, Perfect structure, stable performance, convenient operation and longevity of service etc. It is widely employed in mining, tunnel, culvert, subway, hydropower engineering, underground excavation engineering etc.

 GZ5V mechanical variable gearbox dry mix concrete shotcrete machine



Technical data



GZ5V mechanical variable gearbox dry mix concrete shotcrete machine data:

Output Capacity

1-5m ³/h

Max. horizontal conveying distance

200m

Suitable mix ratio (cement/sand)

≤1:4-5

Max. aggregate size

15mm

conveying hose inner diameter

51mm

Conveying pressure

0.2-0.4MPa

Air consumption

7-8m ³/min

Material charging height

1.1m

Rotor speed

2.2-11r/min

Electric motor type

Y132M-4

power

7.5kW/10hp

Overall dimension (length×width×height)

1.42×0.75×1.2m

Net weight

750kg





Accessories



 Spare parts:

GZ5V mechanical variable gearbox dry mix concrete shotcrete machine
