GD-SL medium pressure flexible hose grouting screw pump
GD-SL medium pressure flexible hose grouting screw pump description:
GD-SL medium pressure flexible hose grouting screw pump is medium pressure flexible-hose grouting pump. It’s suitable for spraying cement paste, dry cement paste, self-flow refractory castables and wet material with max. aggregate 3mm.
This machine discharge steady and uniformly, pulsation-free. It can be used for wet spraying, pouring, grouting for many kinds of metallurgicalfurnace.
GD-SL medium pressure flexible hose grouting screw pump parameter:
Model |
Working pressure (Mpa) |
Discharge amount (L/min) |
Max. aggregate (mm) |
Conveying distance(m) |
Outlet pipe dia.(mm) |
|
vertical |
horizontal |
|||||
GD-SL0.5 |
≤2 |
8 |
≤1 |
80 |
20 |
20 |
GD-SL1.0 |
≤2 |
16 |
≤2 |
80 |
20 |
25, 20 |
GD-SL2.0 |
≤2 |
32 |
≤3 |
80 |
20 |
32, 25 |
GD-SL3.0 |
≤2 |
50 |
≤3 |
80 |
20 |
32, 40 |
GD-SLT-3.0 |
≤1.8 |
30 |
≤1 |
80 |
20 |
25 |
Remarks:
1, There is blender mixing system for spraying wet material spraying, self-flow refractory cstables and cement slurry with this machine. but a special blender mixing system or blender mixer is needed when use GD-SL 2.0 or GD-SL3.0 for dry cement slurry application.
2, Different model match with different material hose.
3, The dedicated spray gun made by us is needed.
4, GD-SLT-3.0 used for metallurgicalindustry spraying such as oxygenlance spraying, billet surface spraying and motor surface spraying with many kinds of coating
Supply: main machine, blender mixing system (dry cement paste application need blender mixer), air hose, material hose and dedicated spray gun.
