GZ-3E-R Refractory Gunning Machine
GZ-3E-R Refractory Gunning Machine Describe
GZ-3E-R is specifically designed for Refractory Dry-mix shotcrete applications, as well as for concrete shotcrete application.
With this GZ-3E-R, you can get low dust and high performance spraying flow in nozzle.
GZ-3E-R Refractory Gunning Machine Application
1. Gunite Swimming Pool Construction
2. Soil Retention and Retaining Walls
3. Rocks aping
4. Refractory Spraying
5. Mine Support
6. Tunnel Linings
7. Concrete Repair
8. Artificial Rocks and Caves
9. Low-volume Refractory Spraying
GZ-3E-R Refractory Gunning Machine Advantage
1. High quality, reliable performance.
2. Good seal performance, little dust.
3. Reasonable design, convenient to move.
4. Non-adhesion going-through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
5. Thin follow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality.
6. We make it easy to adjust the press between sealing plate and rotor disk so as to no air and dust leak and prolong consumption parts life.
7. Widely used in mining, tunnel, culvert, revetment, etc.
GZ-3E-R Refractory Gunning Machine Technical Data
Specification (with Electric motor drive): | |
Rated Output | 3-5m3 /h |
Max. Horizontal Conveying Distance | 200m |
Max. Aggregate Size | Dia.10 mm |
Conveying Hose Inner Diameter | 38mm |
Operating air Pressure | 0.2-0.4MPa(29-58PSI) |
Air Consumption | 5~6m3/min(180-215CFM) |
Motor Power | 4kw |
Voltage | 3 phase,380V,50Hz |
Material Charging Height | 1.1m |
Rotor Speed | 13.2r/min |
Overall Dimension(L×W×H) | 1130*540*1100mm |
Weight | 430kg |
GZ-3E-R Refractory Gunning Machine Pictures
