GTQ5-12B Hydraulic Machine Electrical Steel Wire Straightener and Cutter

Name: GTQ5-12B Hydraulic Machine Electrical Steel Wire Straightener and Cutter
Brand: TECH
SKU: 141384796
Availability: InStock

Henan Taike Industrial And Equipment Co., Ltd. Gold Verified Supplier

5Yrs

US$ 2,500 - 4,500 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Straightener & Cutter

Use:

Bar

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjing/shanghai/qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Straightener & Cutter

Use Bar

Place of Origin Henan, China

Brand Name TECH

Model Number GTQ5-12B

Voltage 380V

Power(W) 11KW

Dimension(L*W*H) 2200*690*1160mm

Weight 900kg

Certification ISO9000

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

GTQ5-12B electrical steel wire straightener and cutter

Usage: suitable for straightening and cutting of 4-14mm round steel and 4-12mm

deformed steel. Automatic CNC system makes it easy to operate and improve the working efficiency and straightening accuracy.

Especially suitable for big building site and metal processing company.

Main data for electrical steel wire straightener and cutter

Model:GTQ5-12B

Straightening diameter: Φ4 to Φ12mm

Straightening wheels: 6 pics
Speed of working: 35-45m/min

Cutting space: 900mm (can be longer)
Cutting length error: ±0.5cm
Straightening accuracy: ±2mm/m
Motor power: 11KW

Overall size: 2200*700*1100mm

Weight: 900kgs

Straightening diameter	φ4 –φ12 mm
No. of straightening wheel	6 pics
Speed of working	35-45 m/min (high/low speed adjustable)
Cutting space	800-900 mm (can be longer)
Error of cutting length	±0.5cm
Straightening accuracy	±2mm/m
Motor power	11 KW
Overall size	2200×690×1160(mm)
Gross weight	900 kg
