LPS-7 stepless speed change multifunction hydraulic wet spraying pump
LPS-7 stepless speed change multifunction hydraulic wet spraying pump description:
LPS-7 stepless speed change multifunction hydraulic wet spraying pump mainly used for wet spraying for roads, railways, mining and tunnel, spraying mixed vegetation for slope of road and railway, grouting for wall, pumping fine aggregate concrete and so on. It’s adopted internationally hydraulically driven wet spray technology, thus transmission distance and height increased 3-5 times than the rotor wet spray machine.
LPS-7 stepless speed change multifunction hydraulic wet spraying pump features:
1, Wet spraying machine has stepless speed change. The conveying output is 0-7 cubic meters / hour.
2, The machine has hydraulic power. The export is connected with high pressure hose. The nozzle is connected with a small 10 cubic meters of air compressors to achieve wet spraying. This changed the traditional use of large 20 cubic meters of air compressor.
3, Compared with rotary pneumatic wet spraying machine, this machine has a smaller size, superior performance, lower maintenance costs, easier to operation, better flexibility, and widely range of applications
LPS-7 stepless speed change multifunction hydraulic wet spraying pump
LPS-7 stepless speed change multifunction hydraulic wet spraying pump data:
Parameter |
Unit |
Data |
|
Productivity |
m3/h |
7 |
|
Max. particle size |
mm |
15 |
|
Fineness modulus of aggregate |
|
≥2.5 |
|
Dosage of liquid accelerator |
% |
3.5 |
|
Conveying hose ID |
mm |
51 (2″) |
|
Concrete slump |
cm |
8~15 |
|
Systematic air pressure |
MPa |
≥0.5 |
|
Pump outlet pressure |
MPa |
6 |
|
Air consumption |
m3/min |
≤6 |
|
Max. conveying distance |
Horizontal |
m |
300 |
Vertical |
m |
80 |
|
Dust alongside machine |
mg/m3 |
<6 |
|
Rebound(Under standard technology) |
% |
Average≤15 |
|
Motor power |
kW |
11/15 |
|
Gauge |
mm |
600.762.900 |
|
Overall dimension(Tyre type)(L×W×H) |
mm |
2500×1010×1450 |
|
Weight |
kg |
960 |
|
Note: It’s optional for tyre type and track type walking structure.
A complete set of wet shotcrete machine
No. |
Name |
Model |
Unit |
Qty. |
1 |
High pressure conveying hose |
2"×15M |
pcs |
1 |
2 |
reducer |
3"-2" |
pcs |
1 |
3 |
High pressure conveying elbow |
3"×90° |
pcs |
2 |
4 |
High pressure conveying pipe clamp |
3" |
pcs |
3 |
5 |
High pressure conveying pipe clamp |
2" |
pcs |
2 |
6 |
Nozzle assy. |
2" |
set |
1 |
7 |
Air hose |
1"×25M |
pcs |
1 |
8 |
Hose for additive |
20M |
pcs |
1 |
Package
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD33000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
