LEC Prestressed Concrete Post Tension Hydraulic Jack Oil Pump Price
Specification:
electric oil pump for prestress tension hydraulic jack
1. Type: YBZ2×2/50A, YBZ2×1.5/63, YB4/80
2. Features:
A: YBZ2x2/50A is a plunger type high voltage high pressure oil pump, matched jacks: QYC240, QYC270 Front End Jack, YDC650, YDC1000, YDC1500, YDC2000, YDC3000, YDC3500, YDC4000, YDC4500, YDC5000, YDC6500 Cross Core Hollow jack, GYJ Extruding Machine, YH30 Embossing Machine, and Button-head Device. Besides, it aslo matched with low flow and high pressure jacks and hydraulic machinery to work.
B:YBZ2x1.5/63 is a oil pump designed for the large tonnage hydaulic jacks in post tensioning and prestressing work. Its rated oil output will be doubled if the stroke of jacks are hollow or jacks are at low pressure work. Then the running speed of jacks will be accerlerated alomost one time under that conditions. But it will be incresed automaticly when tensioning high pressure work, thus the steafy of tensioning and prestressing can be guaranted.
C:YB4/50 elecric hydraulic oil pump. We are the exclusive manufacure of developing and producing oil pump that can separately feed oil for two jacks at same time. It is our new type and widely used in post tensioning and prestressing work.
3. Applications: Large –span bridges on railway and highway, overhead crane beam, rock-soil anchoring project, multi-story industrial buildings, stadiums, coal mines and etc.
4. Our Advantages: We supply full complete set anchor system and equipment for construction, please see following
A: Mono strand anchor system: 5mm,7mm, 8.0mm, 9.0(9.52mm) anchors for steel wire
B: Multi strand anchor system: 9.52mm, 12.7mm, 12.9mm, 15.24mm, 15.7mm, 21.6mm, 22mm anchors for pc strand.
C: Steel rear anchor system: 16mm, 18mm. 22mm, 24mm, 26mm, 28mm, 32mm, ect.
D: Equipment: hydraulic jack, oil pump, metal ducts making machine, pc strand(steel wire) pulling machine, grout pump and mixer, vacuum pump, embosisng machine(bulding jack), extruding machine, ect.
E: Building materials: 12.7mm, 15.24mm, 9.53mm unbonded pc strand, bonded(bare) pc strand, metal ducts, plastic ducts, steel strip.
YB series electric oil pump for prestress tension hydraulic jack
YB series electric oil pump for prestress tension hydraulic jack
| Model |
Rated pressure (Mpa) |
Rated (L/min) |
Net weight (kg) |
Power (KW) |
Volume (L) |
Dimension (mm) |
Purpose |
| YBZ2×2/50A | 50 | 2×2 | 120 | 3 | 60 | 740×450×1050 | Used of various jack, extruder,buttonhead with rated pressure less than 50 Mpa. |
| YBZ2×1.5/63 | 63 | 2×1.5 | 124 | 3 | 60 | 740×490×880 | Used of various jack, extruder, buttonhead with rated pressure less than 63 Mpa. |
| YB4/80 | 80 | 4 | 270 | 4 | 60 | 1090×590×1120 | Have the performance of big flow,high pressure, can separately feed oil for two jacks. |
1. The pictures of electric oil pump for prestress tension hydraulic jack
2. YDC series of jacks and its matached oil pump for construction
3. Mutistrands anchor system and equipment for bonded construction
4. Flat anchor system for construction
5. Applications:
Related Equipment:
PC Strands Pusher Machine:
Grout Pump and Grout Mixer Machine:
1. What is your required capacity(tons) for jack?
2. What is your required oil flow volume and voltage?
