small floor heating foammachine
LF series hot sale small floor heating foam concrete machine
This fully foamed concrete equipments operation proceed is automatic, combined the material feeding, foam generating, mixing, and transportation together.The concrete delivering pump, coming with double hydraulic cylinder. Basing on the high output pressure, it can deliver the foam concrete to the high building. It also equips with moving wheels, universal wheels, the stretch frame, easy to move to other sites.
LD-30Foam Concrete Making Machine--Mixer Technical Data:
Model |
LD-2000 |
Production Capacity |
15-20 m³/h |
Output Volume |
1500 L |
Material Input Volume |
2000 L |
Main Shaft Revolution |
32 r/min |
Hopper Lifting speed |
22 m/min |
Mixing Motor |
11 kW |
Winding Motor |
5.5 kW |
Water Pump Motor |
1.1 kW |
Vibrating Motor |
0.55 kW |
Foaming System |
5.5 kW |
Max. Moving Speed |
15 km/h |
Total Weight |
3200 kg |
Overall Dimension |
2600x2250x3000 mm |
LD-30 Foam Concrete Making Machine--Pump Technical Data:
Model |
LD-30 |
Max.Output |
30 m³/h |
Max.Conveying Pressure |
8 MPa |
Max.Horizontal Transporting Range |
600 m |
Max. Vertical Transporting Height |
200 m |
Max. Particle Size of Aggregates |
8 mm |
Cylinder Bore |
80 mm |
Delivery Cylinder Bore |
140 mm |
Max.Pressure of Hydraulic System |
24 MPa |
Oil Pressure Box Volume |
200 L |
Motor Power |
30 kW |
Total Weight |
2200 kg |
Overall Dimension |
3100x920 x1300 mm |
Foam Concrete Making Machine's Features:
- Heat resistance
- lightweight, high-strength
- sound insulation
- Fireproofing, aseismatic, safety
- High construction speed
- Environmental friendly
- User friendly with costomization
- Low cost, long durable
- Fit to Low budget
A complete of Foam Concrete Making Machine Line:
- Foam Concrete Mixer
- Foam Concrete Pump
- Foam Concrete Block Mould
- FoamConcrete Block Cutting Machine
- Foaming Machine
- Foaming Agent
- Foam Concrete Hardener
The other Application and advantage as follow:
1. Precast wall panels;
2. Cast wall in construction site;
3. Roofing insulation and flooring insulation;
4. Gap filling;
5. Sound inslution layer, tunnel lining filling;
6. Platform filling and mending.
Mixer and Pump Detailed Parts Pictures:
Working Pictures:
Package & Shipping
It usually shipped by a 40'' container:
concrete mixer (2600*2250*3000mm ,Net weight 3200kg);
concrete pump (3100*920*1300mm,Net weight 2200kg).
OUR service:
To provide a world best quality of product and service with 100% customer focused. We strive always for honesty and best quality of products and devote ourself to become a foremost seller in foam concrete products, as well as to provide customer focused Products on time with integrity.
Thank you for stop here to look through our products, for getting offer for your project please contact with us freely.
