Electric Concrete Placing Boom for Construction
Trade Assurance:
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD13000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
Product Discription:
BLG12m, BLG15m, BLG18m Full Circle Swinging Concrete Placing Boom , is designed by ourselves company and matching with concrete pump truck and trailer concrete pump equipment. It mainly used for construction of concrete poured on the site, reasonable design, flexible rotation, reliable, can be rotate at 360°omni-directional clockwise and counter clockwise, concrete pipeline made up from standard pipe diameter and pipe joint, convenient to connect with pump pipe.
Technical Data:
Model | LEB-12 | LEB-15 | LEB-18 |
Rotary Type | Electric | Electric | Electric |
Radius of Placing Boom | 12m | 15m | 18m |
Placing Height | 4m | 4m | 4m |
Delivery Pipe Diameter (mm) | 125 | 125 | 125 |
Pipe Thickness(mm) | 4.25 | 4.25 | 4.25 |
Bending Thickness(mm) | 4.5 | 4.5 | 4.5 |
Slewing Range | 0-360° | 0-360° | 0-360° |
Supporting Leg Span(m) | 3.2*3.2 | 4*4 | 4*4 |
Material | Channel steel angle iron | Channel steel angle iron | Channel steel angle iron |
Rotary Supporting Type | 315 | 315 | 380 |
Overall Weight | 1100KG | 1500KG | 1600KG |
Counterweight | 600KG | 800KG | 1000KG |
Other Model Concreter Placing Boom:
