Welding electrodes
Welding electrodes introduction
E316L-16 is a kind of ultra-low-carbon Cr18Ni12Mo2 stainless steel electrode with lime-titania type coating. The carbon content of the deposited metal is lower than or equal to 0.04%. It has excellent heat-resistance, corrosion-resistance, crack-resistance, blowhole-resistance and welding performance. The coating has red-resistance and high strength. AC/DC.
Usage:
Used for welding equipment of urea, synthetic fiber, etc. and stainless steel structures of the same types, and also used for Cr stainless steel which does not need heat treatment after welding, composite steel, dissimilar steel, etc.
Chemical Composition of Deposited Metal (%)
Chemical Composition | C | Mn | Si | S | P | Cu | Ni | Mo | Cr |
Guarantee Value | ≤0.04 | 0.5~2.5 | ≤0.90 | ≤0.030 | ≤0.040 | ≤0.75 | 11.0~14.0 | 2.00~3.00 | 17.0~20.0 |
Mechanical Properties of Deposited Metal
Test Item | Rm(MPa) | A(%) |
Guarantee Value | ≥490 | ≥30 |
Reference Current ( DC+)
Electrode Diameter(mm) | φ2.0 | φ2.5 | φ3.2 | φ4.0 | φ5.0 |
Welding Current (A) | 40~80 | 50~100 | 70~130 | 100~160 | 140~200 |
Instructions:
1.The electrodes should be baked under 200-250℃ for an hour before welding.
2.Direct current had better be used and the current should not be too strong.
Welding electrodes packing:5kgs/box, 20kgs/carton, 1000kgs/pallet, we could do according to the customers ‘request.
Welding electrodes
Samples:
Supply you 1-2kg welding electrode free of charge to test the quality , Postage will be on the customer’s charge. But postage could be deducted from the first order.
Inspection:
Full-Inspection before delivery. Third party inspection: BV SGS CCIC COC CIQ all accepted .
Information Needed to Get a Quotation:
Model, Diameter, Packing and Quantity, such as welding electrode E316L-16, 3.2mm, 5kgs/box,21 tons
How to place order?
welding electrodes manufacturerwelding electrodes manufacturning process:
welding electrodes
1. Are samples available ?
Answer:We are happy to provide free samples to you after you accept
our quotation and really want to cooperate with us.
2. Is OEM available?
Answer:Yes,because we usually do it like that.
3. What's your company normal payment terms?
Answer:Usually we accept T/T,30%T/T prepaid before production,70% T/T in 3 daysafter you see the copy of BL. If you are one real buyer,we also can accept L/C at
sight.
4. How many days it will take you to produce mass production for us?
Answer:Usually it takes about 7to15 days ,it also depends on the
quantity and production seasons.
5.Where is your factory located? Can I visit there?
Answer:Our factory is located in Tianjin City, China, near to Beijing. You are warmly welcomed to visit us!
Your favorable inquiry shall be highly appriciated, my friend!
