Food Processing Autoclave Sterilizer Autoclave for Sea Food in Tin Can

Wenzhou Longwan Wan Yuan Food Machinery Factory
Food Processing Autoclave Sterilizer Autoclave for Sea Food in Tin Can thumbnail-1
Food Processing Autoclave Sterilizer Autoclave for Sea Food in Tin Can photo-1
US$ 7,000 - 9,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
wanyuan
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo / shanghai / qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name wanyuan
Model Number GT7CW 720
Usage Other, Fruit & Vegetable
Type Autoclave
Voltage 110V / 220V / 380V / 415V
Power(W) 3KW
Weight 400kg
Dimension(L*W*H) 2000 x 1400 x 1600 mm
Certification CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Product Description



what is a autoclave?

autoclave is a kind of back pressure vessel, mainly ued to the sterilization of sea food in tin can, glass jar or vegetable in vacuum package.  of course, this kind of autoclave can be also used to other food in glass bottle and platic botles.



autoclave can be called as autoclave sterilizer, or sterilizer. some times people call them retort or retort sterilizer.

food processing autoclave sterilizer autoclave for sea food in tin can


Our Services





Model GT7CW720
production capacity720
(cans/batch)
Pot body size(mm)Φ900*1500
volume (m3)1.1
design temperature(0C)143 0C
operating temperature(0C)≤138 0C
design pressure(Mpa)0.3MPa
working pressure(Mpa)steam≤0.25Mpa  electrical heating≤0.16Mpa
working mediumSalt, water, steam, compressed air
The main pressure parts materialSS303 / SS316 / carbon steel Q235-A
welding coefficient0.7
corrosion allowance1mm
Steam inlet diameterDN40-50
Exhaust diameterDN32-40
Cool and hot water Connection pipe diameterDN40-50
Overflow pipe diameterDN25-50
Water outlet Pipe diameterDN40-50
Safe valve diameter(mm)DN25-50
Compressed air diameter(mm)DN15-20
Adjust mouth diameter(mm)DN25-40
Steel Thickness (mm)6(thickness can be adjust according to request)
Total Weight (kg)700
overall dimension2000*1450*1232
mm(L×H×W)




Packaging & Shipping



our autoclave sterilizer usually packaged in wooden case which is suitable for sea transport
