Water Spray Sterilizer Steam Spray Steilizer Retort

FOB Price

US$ 5,000 - 9,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Zhejiang, China
Brand Name	wanyuan	Model Number	DN1100x2000
Usage	Canned Food	Type	Autoclave
Voltage	220V 380V 450V	Power(W)	16KW
Weight	1200KG	Dimension(LWH)	1300x3000x1800
Certification	CE	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

water spray sterilizer steam heating sterilizer

Model	GT7CW720	GT7CW1200	GT7CW2000	GT7CW2400
					production capacity (cans/batch)	720	1200	2000	2400
Pot body size(mm)	Φ900*1500	Φ1100*2000	Φ1200*3000	Φ1200*3500
volume (m3)	1.1	2.2	3.9	4.5
design temperature(0C)	143 0C
operating temperature(0C)	≤138 0C
design pressure(Mpa)	0.3MPa
working pressure(Mpa)	steam≤0.25Mpa electrical heating≤0.16Mpa
working medium	Salt, water, steam, compressed air
The main pressure parts material	SS303 / SS316 / carbon steel Q235-A
welding coefficient	0.7
corrosion allowance	1mm
Steam inlet diameter	DN40-50
Exhaust diameter	DN32-40
Cool and hot water Connection pipe diameter	DN40-50
Overflow pipe diameter	DN25-50
Water outlet Pipe diameter	DN40-50
Safe valve diameter(mm)	DN25-50
Compressed air diameter(mm)	DN15-20
Adjust mouth diameter(mm)	DN25-40
Steel Thickness (mm)	6(thickness can be adjust according to request)
Total Weight (kg)	700	982	1302	1391
overall dimension mm(L×H×W)	200014501232	252016001440	355017501550	405017501550

high pressure steam sterilizer sterilizer retort picture

sterilizer retort for meat , juice bottle , pouch

made of stainless steel with automatic temp control

water spray sterilizer steam heating sterilizer
