Characteristics:
The host of automatic sterilizer of milk and yoghourt is high temperature sterilizer. The machine has characteristics such as compact structure, effective sterilization, convenient operation,wide adaptation,low cost and so on.
Application:
It is widely used in milk, juice, tea drinks, milk drinks, ketchup, condiments, beer, butter, ice cream, egg products, powder and other products.
Feature:
1.The huge viscosity range. The use environment PH value is 1-14. It is suitable for sterile production of fresh milk, pasteurized milk, yogurt, colored milk, juice, tea drinks, wine, ice cream, soy milk, beverage, jam, butter and other products. The products produced by UHT sterilization system can maintain 3-6 months under normal temperature (do not add any preservatives), thus eliminating the cold chain.
2.The equipment is automatically or semi-automatically controlled by computer with LCD
touch screen operation.
3.Instantaneous processing maintain the original flavor of the products.
4.PID temperature control system, sterilization temperature recorded continuously in real time.
5.The product has uniform heat treatment, heat recovery up to 90%.
6.The tube inside without any contact, no health dead corners, the product will not adhere to the tube, and the bellows can form high turbulence in sterilization process, with a self-cleaning effect, so it is difficult to form tube fouling and pollution.
7.With a long continuous operating time and good CIP self-cleaning effect
8.Less spare parts, low operating costs
9.Easy to install, inspect and remove, convenient to maintain pipeline.
10.Reliable material, affordable a higher product pressure.
Technical parameters
| model and specification | capacity | steam consumption | steam pressure | power | outline dimensions of integral type | outline dimensions of split type | weight | pipe diameter | ||
| t/h | kg/h | bar | kw | l*w*h | l*w*h | kg | material | steam | mediu | |
| TG-UHT-1MQJ | 1 | 40 | 6.0 | 4.0 | 3.3*1.6*1.8 | 1960 | 25 | DN25 | 25 | |
| TG-UHT-1.5MQJ | 1.5 | 60 | 6.0 | 4.0 | 3.3*1.6*1.8 | 1960 | 25 | DN25 | 25 | |
| TG-UHT-2MQJ | 2 | 80 | 6.0 | 6.0 | 3.5*1.8*2.0 | 2160 | 38 | DN25 | 38 | |
| TG-UHT-3MQJ | 3 | 120 | 6.0 | 6.0 | 3.5*1.8*2.0 | 2420 | 38 | DN32 | 38 | |
| TG-UHT-4MQJ | 4 | 160 | 6.0 | 7.0 | 4.5*2.0*2.0 | 6.5*0.9*1.4 | 2570 | 38 | DN32 | 38 |
| TG-UHT-5MQJ | 5 | 200 | 6.0 | 7.0 | 4.5*1.8*2.0 | 6.5*0.9*1.4 | 2940 | 51 | DN40 | 51 |
| TG-UHT-6MQJ | 6 | 240 | 6.0 | 7.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 3300 | 51 | DN40 | 51 |
| TG-UHT-8MQJ | 8 | 320 | 6.0 | 11.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 3700 | 51 | DN50 | 51 |
| TG-UHT-10MQJ | 10 | 400 | 6.0 | 11.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 4200 | 51 | DN50 | 51 |
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Choose us and get more benefits:
1. Deliver innovative products in the market at a faster pace;
2. Enhance the reliability of product’s quality;
3. Decrease the total cost of the product effectively;
4. Improve research personnel’s ability of creative design;
5. Gain more leading technologies about product development and increase the competitive advantage of products.
Pre-sale service:
1. Free of making offers, craft and technical guidance.
2. We can provide company’s qualification certification and the drawings.
3. We can also make customized products according to customer’s needs.
After-sale service:
1. We provide long-term after-sale service.
2. Meanwhile, you can call or e-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
We can offer several payment methods which can ensure your capital’s security, such as the following:
L/C T/T D/A D/P
Western Union
MoneyGram
