Beverage steurilizer unit
1.used for sterilization for milk, juice and ice cream etc.
2.the temperature can be set by .
Technical Parameter of plate pasteurizer:
5→65(homogenization)→85(15S) →5
| Model | size | steam consume | steam pressure | ice water consume | ice water flow | electrical power | outside measure | weight | pipe size | ||
| t/h | kg/h | bar | Kca/h | t/h | kw | l*w*h | kg | material | steam | medium | |
| BR16-PUT-SN-1t | 1 | 40/76 | 4.0 | 20,000 | 3 | 3.0 | 1.6*1.4*1.8 | 730 | 32 | DN25 | 32 |
| BR26-PUT-SN-2t | 2 | 80/152 | 4.0 | 40,000 | 6 | 4 | 1.6*1.4*1.8 | 910 | 32 | DN25 | 32 |
| BR26-PUT-SN-3t | 3 | 120/228 | 4.0 | 60,000 | 9 | 4 | 1.8*1.6*2.0 | 940 | 38 | DN25 | 38 |
| BR26-PUT-SN-4t | 4 | 160/304 | 4.0 | 80,000 | 12 | 6 | 2.0*1.6*2.0 | 970 | 38 | DN32 | 51 |
| BR26-PUT-SN-5t | 5 | 200/380 | 4.0 | 100,000 | 15 | 6 | 2.2*1.6*2.0 | 1030 | 51 | DN32 | 51 |
Production capacity: 500L-20T/H
This unit can be connected with separator, homogenizer, flash evaporator & degasser etc. This unit is used as Pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, ice cream etc.), and also pre-sterilize material when producing Pasteurized milk (long life milk).
This machine has features of high heat recovery, lower energy cost, strict design on the construction and easy operation, simple maintenance.
Control type: Full-automatic control (PLC with touch screen), semi automatic.
Standard attachments:
A. plate heat exchanger; B. material-balance bucket;
C. hot water-balance drum; D. hot water pump; E. product pump;
F. steam & water mixer; G. electricity box;
H. stainless steel pipes and valves etc . I.PLC and color touch screen or PID
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
