Water Bottling Equipment
(1) This drinking water bottling equipment is mainly used for washing, filling and capping PET bottle which can fill non- carbonated drinks such as mineral water, pure water, wine and so on.
(2) Bottle washing, filling and capping of the drinking water bottling equipment are achieved in one machine.
(3) The contact time is shorten between material and the outside. And improved the health conditions, production capacity and economic benefits.
(4) CGF series drinking water bottling equipment adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster and more laborsaving.
(5) The main machine of the drinking water bottling equipment adopts advanced PLC control technology. The key electric elements adopt Mitsubishi, Omron, Siemens, etc international famous products.
SPECIFICATION for Water Bottling Equipment :
| Model | CGF8-8-3 | CGF16-12-6 | CGF18-18-6 | CGF24-24-8 | |
| Number of rinsing head | 8 | 16 | 18 | 24 | |
| Number of filling head | 8 | 12 | 18 | 24 | |
| Number of capping head | 3 | 6 | 6 | 8 | |
| Rated production capacity | 3000BPH | 4000BPH | 6000BPH | 10000BPH | |
| Installed capacity | 3 | 3.5 | 4 | 4.8 | |
| Overall size | 1900×1420×2000 | 2200×1600×2300 | 2450×1900×2300 | 2750×2180×2400 | |
| Model | CGF32-32-10 | CGF40-40-12 | CGF50-50-15 | |
| Number of rinsing head | 32 | 40 | 50 | |
| Number of filling head | 32 | 40 | 50 | |
| Number of capping head | 10 | 12 | 15 | |
| Rated production capacity | 12000BPH | 16000BPH | 24000BPH | |
| Installed capacity | 7.6 | 8.3 | 9.6 | |
| Overall size | 4000×2300×2300 | 4550×2650×2300 | 5450×3210×2300 | |
